MSD 6430 Part Description
Manufacturer
Product Description
MSD 6ALN Ignition Control
Features & Benefits
- Works on 12 - 18 volt electrical system
- Multiple spark, capacitive discharge ignition control
- Supplied with rubber shock mounts
- 6-pin Weathertight connector, mandatory for NASCAR use
- Multiple sparks for 20 degrees of crankshaft rotation
- Designed for circle track racing with NASCAR mandated connectors and clear epoxy potting compound for vibration protection
- Circuit board is encased in a clear two part silicone elastomer
- Built-in Soft Touch Rev Control is adjustable with RPM Modules
- 470 primary voltage output to coil
- Supplied with 3,000, 6,000, 7,000 & 8,000 RPM Modules
- Programmable for 4, 6, or 8-cylinders by cutting red/blue wire loops
- 110 millijoules per spark up to 15,000 RPM
- Accepts breaker points, amplifier and magnetic pickup trigger inputs
- Clear plastic base plate for easy tech inspection
MSD 6430 Specifications
Product Attributes
| Brand | MSD |
| Category | Ignition |
| Color | Red |
| Connector Gender | Male Female |
| Connector Quantity | 2 |
| Emission Code | 4 |
| Grade Type | Performance |
| Height | 2.9 IN |
| Ignition Type | Performance |
| Length | 10.8 IN |
| Maximum RPM | 15,000 RPM |
| Mount Type | Surface Mount |
| Mounting Hardware Included | Yes |
| Primary Voltage | 470 |
| Product Type | Ignition Box |
| Spark Energy (mJ per spark) | 110 |
| Sub Category | Control Modules |
| Terminal Gender | Male Female |
| Terminal Quantity | 9 |
| Voltage Required | 12-18 |
| Warning | California Proposition 65 |
| Warranty | Manufacturer's Limited 1 Year Warranty |
| Width | 9.8 IN |
Additional Information
| Original Supplier | US |
| Warranty Special | Manufacturer's Limited 1 Year Warranty |
| Warranty Special UOM | TX |
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 8511804000 |
| Harmonized Tariff Code (HTS) | 8537109160 |
| NAFTA Preference Criterion Code | B |
| UPC | 00085132064304 |
