WAGNER BD126193E Part Description
Manufacturer
Product Description
Disc Brake Rotor
Application Summary
2006-2011 Cadillac STS (Front) (Qualifier: with Brembo Brake System, 6 Stud Wheel, with 355 (mm) Diameter Rotor, Black E-Coat on non-braking surface to prevent rust and corrosion); 2004-2007 Cadillac CTS (Front) (Qualifier: 6 Stud Wheel, with 355 (mm) Diameter Rotor, Black E-Coat on non-braking surface to prevent rust and corrosion, with Sport Suspension)
Features & Benefits
- ENGINEERED FOR PERFORMANCE -- OE-specific vane design provides effective braking power and heat dissipation while controlling noise, vibration and harshness
- OE-STYLE DESIGN -- Restores like-new braking performance while matching OE fit, form and function
- PREMIUM PROTECTION -- E-Shield(R) protective coating is applied to non-braking surfaces to inhibit corrosion
- RESISTS CORROSION -- Painted edges & hats provide reliable corrosion resistance
- TURNED AND SMOOTH FINISH -- Requires less pad break-in time and aids in proper bedding
- NON-DIRECTIONAL FINISH -- Reduces pad break-in time and promotes proper bedding for consistent stopping power
- EASY INSTALLATION -- Rotors are packaged in a Vapor Corrosion Inhibitor bag, eliminating the need for an oil coating which reduces prep time
- CONSISTENT PERFORMANCE -- Precision ground surface finish delivers reliable performance, noise reduction and heat dissipation
- PROPER BALANCE -- Spin balanced and cut to limit vibration for improving stability and control
- SMOOTH BRAKING -- Application-specific OE vane design and thickness help control noise, vibration and harshness (NVH)
- PERFECT PAIRING -- Pair Wagner premium rotors with premium brake pads for optimal performance
- BALANCED FOR SMOOTH STOPS -- Precision-balanced to minimize pedal pulsation and deliver a smoother ride
- QUALITY MATERIALS -- Proven metallurgy provides structural integrity and heat dispersion for reliable performance
- EASY TO INSTALL -- Simply wash the oil off and bolt on; no machining required
- COMPREHENSIVE COVERAGE -- Available for foreign and domestic nameplates
- PERFECT PAIRING -- Pair Wagner® Standard rotors with Wagner brake pads and calipers (sold separately) for optimal performance
- PERFECT PAIRING -- Pair Wagner(R) Standard rotors with Wagner brake pads and calipers (sold separately) for optimal performance
WAGNER BD126193E Specifications
Product Attributes
| Material | Cast Iron |
| Nominal Thickness | 1.260 IN |
| Disc Finish | Directional |
| Construction | Full Cast |
| Rust Resistant Coating | Yes |
| Outside Diameter | 13.960 IN |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Height | 1.962 in |
| Part Description | Disc Brake Rotor |
| Nominal Thickness | 32.0 MM |
| Height | 49.8 MM |
| Stud/Lug Hole Quantity | 6 |
| Outside Diameter | 354.5 MM |
| Overall Height | 49.8 MM |
| Overall Height | 1.962 IN |
| Bearings Included | No |
| Directional or Non-Directional Brake Surface | Directional |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708305030 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00008536948254 |
| VMRS Code | 013017001 |
| UNSPSC | 25171705 |
WAGNER BD126193E Cross References
| Brand | Part Number |
|---|---|
| ACDelco | 18A2428A, 18A2428SD |
| Aimco | 55145 |
| Autospecialty | AR82105 |
| Bosch | 25011448 |
| BrakeBest Select Drum/Rotor | 580266RGS |
| Carquest Wearever | YH145742 |
| Centric Parts | 120.62075, 121.62075, 12062075, 12162075, 125.62075, 125.62075CRY |
| DuraGo | BR900554 |
| Duralast | 41130 |
| Dynamic Friction Company | 600-46015, 604-46015 |
| General Motors | 25750248 |
| NAPA | 880266 |
| NAPA BRAKES | 880266CR, 48880266 |
| PowerStop | AR82105, AR82105EVC |
| RAYBESTOS | 580266, 580266R |
| Raybestos Brakes | 580266, 580266R, 580266PER |
WAGNER BD126193E Fits Vehicles
- Cadillac STS (2005-2011)
- Cadillac CTS (2004-2007)
