(888) 312-8812 Login SignupWAGNER BD125678E Wagner BD125678E Brake Rotor
Tap to view 2 more
$78.34
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
WAGNER BD125678E Part Description
Manufacturer
Product Description
Brake Rotor
Application Summary
Ford Windstar (F) 03-99
Features & Benefits
- ENGINEERED FOR PERFORMANCE -- OE-specific vane design provides effective braking power and heat dissipation while controlling noise, vibration and harshness
- OE-STYLE DESIGN -- Restores like-new braking performance while matching OE fit, form and function
- PREMIUM PROTECTION -- E-Shield® protective coating is applied to non-braking surfaces to inhibit corrosion
- RESISTS CORROSION -- Painted edges & hats provide reliable corrosion resistance
- TURNED AND SMOOTH FINISH -- Requires less pad break-in time and aids in proper bedding
- NON-DIRECTIONAL FINISH -- Reduces pad break-in time and promotes proper bedding for consistent stopping power
- EASY INSTALLATION -- Rotors are packaged in a Vapor Corrosion Inhibitor bag, eliminating the need for an oil coating which reduces prep time
- CONSISTENT PERFORMANCE -- Precision ground surface finish delivers reliable performance, noise reduction and heat dissipation
- PROPER BALANCE -- Spin balanced and cut to limit vibration for improving stability and control
- SMOOTH BRAKING -- Application-specific OE vane design and thickness help control noise, vibration and harshness (NVH)
- PERFECT PAIRING -- Pair Wagner premium rotors with premium brake pads for optimal performance
- BALANCED FOR SMOOTH STOPS -- Precision-balanced to minimize pedal pulsation and deliver a smoother ride
- QUALITY MATERIALS -- Proven metallurgy provides structural integrity and heat dispersion for reliable performance
- EASY TO INSTALL -- Simply wash the oil off and bolt on; no machining required
- COMPREHENSIVE COVERAGE -- Available for foreign and domestic nameplates
- PERFECT PAIRING -- Pair Wagner® Standard rotors with Wagner brake pads and calipers (sold separately) for optimal performance
WAGNER BD125678E Specifications
Product Attributes
| Material | Cast Iron |
| Nominal Thickness | 1.017 IN |
| Nominal Thickness | 25.8 MM |
| Disc Finish | Directional |
| Construction | Full Cast |
| Rust Resistant Coating | Yes |
| Outside Diameter | 11.092 IN |
| Outside Diameter | 281.7 MM |
| Height | 1.831 IN |
| Height | 46.5 MM |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| Overall Height | 46.5 MM |
| Overall Height | 1.831 IN |
| Part Description | Disc Brake Rotor |
| ABS Tone Ring Included | No |
| Bearings Included | No |
| Center Hole Diameter | 2.799 IN |
| Center Hole Diameter | 71.1 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 24.7 MM |
| Discard Thickness | 0.972 IN |
| Mounting Bolt Hole Circle Diameter | 4.250 IN |
| Mounting Bolt Hole Circle Diameter | 108.0 MM |
| Mounting Bolt Hole Diameter | 14.2 MM |
| Mounting Bolt Hole Diameter | 0.558 IN |
| Prop 65 Label (Yes/No) | No |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8302303060 |
| Remanufactured Part | N |
| UPC | 00008536947073 |
| VMRS Code | 013017001 |
| UNSPSC | 25171715 |
WAGNER BD125678E Cross References
| Brand | Part Number |
|---|---|
| Aimco | 54070 |
| Autospecialty | AR-8157, AR8157 |
| Bendix | 145244 |
| Bosch | 20010318 |
| Brembo | 27094 |
| CENTRIC | 120.61057 |
| Carquest | 54070 |
| Centric Parts | 120.61057, 121.61057 |
| DuraGo | BR54070 |
| Duralast | 54070, 54070DG |
| Dynamic Friction Company | 600-54085 |
| Ford | 3F2Z1125BA, XF2Z1125AA, YF2Z1V125C |
| NAPA | 4886833, 86683, 86833 |
| PowerStop | AR8157, AR8157EVC |
| RAYBESTOS | 66833, 66833R |
| Raybestos Brakes | 66833, 66833R, 66833FZN |
| Universal | 102588 |
