WAGNER BD125321E Part Description
Manufacturer
Product Description
Brake Rotor
Application Summary
Infiniti G20 (F) 02-99; Nissan Altima (F) 01-93; Sentra (F) 01-00
Features & Benefits
- ENGINEERED FOR PERFORMANCE -- OE-specific vane design provides effective braking power and heat dissipation while controlling noise, vibration and harshness
- OE-STYLE DESIGN -- Restores like-new braking performance while matching OE fit, form and function
- PREMIUM PROTECTION -- E-Shield® protective coating is applied to non-braking surfaces to inhibit corrosion
- RESISTS CORROSION -- Painted edges & hats provide reliable corrosion resistance
- TURNED AND SMOOTH FINISH -- Requires less pad break-in time and aids in proper bedding
- NON-DIRECTIONAL FINISH -- Reduces pad break-in time and promotes proper bedding for consistent stopping power
- EASY INSTALLATION -- Rotors are packaged in a Vapor Corrosion Inhibitor bag, eliminating the need for an oil coating which reduces prep time
- CONSISTENT PERFORMANCE -- Precision ground surface finish delivers reliable performance, noise reduction and heat dissipation
- PROPER BALANCE -- Spin balanced and cut to limit vibration for improving stability and control
- SMOOTH BRAKING -- Application-specific OE vane design and thickness help control noise, vibration and harshness (NVH)
- PERFECT PAIRING -- Pair Wagner premium rotors with premium brake pads for optimal performance
- BALANCED FOR SMOOTH STOPS -- Precision-balanced to minimize pedal pulsation and deliver a smoother ride
- QUALITY MATERIALS -- Proven metallurgy provides structural integrity and heat dispersion for reliable performance
- EASY TO INSTALL -- Simply wash the oil off and bolt on; no machining required
- COMPREHENSIVE COVERAGE -- Available for foreign and domestic nameplates
- PERFECT PAIRING -- Pair Wagner® Standard rotors with Wagner brake pads and calipers (sold separately) for optimal performance
WAGNER BD125321E Specifications
Product Attributes
| Material | Cast Iron |
| Nominal Thickness | 0.867 IN |
| Nominal Thickness | 22.0 MM |
| Disc Finish | Directional |
| Construction | Full Cast |
| Rust Resistant Coating | Yes |
| Outside Diameter | 11.010 IN |
| Outside Diameter | 279.6 MM |
| Height | 1.933 IN |
| Height | 49.1 MM |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 4 |
| Overall Height | 49.1 MM |
| Overall Height | 1.933 IN |
| Part Description | Disc Brake Rotor |
| ABS Tone Ring Included | No |
| Bearings Included | No |
| Center Hole Diameter | 68.1 MM |
| Center Hole Diameter | 2.680 IN |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 0.787 IN |
| Discard Thickness | 20.0 MM |
| Mounting Bolt Hole Circle Diameter | 114.3 MM |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Mounting Bolt Hole Diameter | 12.7 MM |
| Mounting Bolt Hole Diameter | 0.500 IN |
| Prop 65 Label (Yes/No) | No |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8302303060 |
| Remanufactured Part | N |
| UPC | 00008536946120 |
| VMRS Code | 013017001 |
| UNSPSC | 25171715 |
WAGNER BD125321E Cross References
| Brand | Part Number |
|---|---|
| ACDelco | 18A589 |
| Aimco | 31057, 31121 |
| Autospecialty | JBR-557, JBR557 |
| Beck/Arnley | 083-2573, 832573 |
| Bendix | 141892 |
| Bosch | 40011031 |
| Brembo | 25315 |
| CENTRIC | 120.42055 |
| Carquest | 31057 |
| Centric Parts | 120.42055, 121.42055, 120.42055CRY, 320.42055F |
| Datsun/Nissan | 4.02E+06, 4.02E+08, 40206-55F01, 40206-7J101, 4020655F03, 402069E001, 4.02E+10, 4020655F01 |
| DuraGo | BR31057-01, BR31057 |
| Duralast | 31057DG, 31057 |
| Dynamic Friction Company | 604-67040, 600-67040 |
| INFINITI | 402067J101 |
| NAPA | 4886363, 86363 |
| Nissan | D020655F0CNW |
| PowerStop | JBR557EVC, JBR557 |
| RAYBESTOS | 96363R, 96363 |
| Raybestos Brakes | 96363, 96363R, 96363FZN |
| Universal | 109800 |
