HALDEX part description

Product Description

LifeSeal+ Air Disc Actuator Type 2030

Application Summary

2030 LifeSeal, AIR DISC

Features & Benefits

Comes with truly sealed double diaphragm to effectively prevent contaminants from reaching the power spring
Uses standard power spring technology for unparalleled force output consistency
With heavy-duty housing to withstand impact and extreme conditions
Engineered smart and road-tested to ensure reliable, durable performance

Haldex LifeSeal Air Brake Spring Brake

Equip your vehicle with a high-quality Haldex LifeSeal air brake spring brake. This product is the only truly sealed double diaphragm spring brake specifically designed for heavy duty applications.

Product Attributes

Air Port Position	0°
Bracket to End of Spring Housing Length	9.04 in.
Freight Class	70
Piggyback Length	6.42 in.
Series	LifeSeal+
Service Chamber Size	20/30
Service Clampband Position	160°
Service Clampband Size	9.41 in.
Service Housing to Push Rod Length	0.59 in.
Spring Housing Flange Size	8.19 in.
Stroke Length	2.5 in.
Stroke Type	Standard
Stud Distance	4.75 in.

Additional Information

Country of Origin (Primary)	MX
Harmonized Tariff Code (Schedule B)	8412310080
Harmonized Tariff Code (HTS)	8412310080
Remanufactured Part	N
Warranty Distance	100000
Warranty Distance UOM	MI
Warranty Special	See Haldex Aftermarket Product warranty Policy (L20221W).pdf
Warranty Time	12
Warranty Time UOM	MO
UPC	00767653370767
VMRS Code	013004027

Haldex® is a Sweden-based manufacturer specializing in brake and air suspension systems for heavy duty vehicles. Its product line consists of brake components for wheel ends, including disc brakes, brake adjusters, and actuators. It also offers air control products such as compressed air dryers, valves, ABS, and EBS. All these Haldex products are designed with safety and efficient operation in mind, cutting down on potential hazards and maintenance costs in the long run. Today, Haldex runs manufacturing and R&D facilities in 19 countries across four continents. It is dedicated to producing high-quality brake and suspension parts for its customers all around the world as well as developing new technologies for the future.
