REACH COOLING 42-10452 Part Description
Manufacturer
Product Description
FREIGHTLINER-STERLING HDX THOMAS 07-16
Application Summary
FREIGHTLINER-STERLING HDX THOMAS 07-16
Features & Benefits
- Deep extrusion headers provide a stronger tube-to-header joint that is more resistant to the effects of vibration and thermal tube expansion.
- Reach B-Type tubes feature central reinforcement to provide greater tolerance to pressure reducing the probability of tube failure.
- Reach utilizes longer header tabs for increased pressure resistance, this reduces the potential for tank-to-header leaks.
- Folded fin edges increase stability and heat disbursement properties.
- Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure. Stronger tube design means drastically reduced probability of tube failure.
- We use longer header tabs for increased pressure resistance. This reduces the potential for tank to header leaks.
- Radiators are the foundation of any engine cooling system. Tasked with preventing the vehicle from overheating, the radiator is vital to keeping vehicles up and running.
- Thermal expansion cuts allow for longer life and reduce failure rates by allowing improved core expansion and contraction during normal heat cycles.
- Our deep extrusion header provides a stronger tube to header joint which is more resistant to the effects of vibration and thermal tube expansion, virtually eliminating tube to header leaks.
- Thermal expansion reduce failure rates by allowing improved core expansion and contraction.
- Our fin edges are folded for increased stability and heat disbursement properties.
- Our included "multi-fit" attachments allow one radiator to cover multiple vehicle applications without sacrificing OE fit. This results in wider vehicle coverage with substantially less inventory.
- We design and manufacture all our radiators to meet or even exceed Original Equipment specifications. We take pride in producing the most reliable replacement parts in the market.
- Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure. Stronger tube design means drastically reduced probability of tube failure.
FREIGHTLINER/STERLING HDX THOMAS 07-16
| Make | Freightliner, Sterling |
| Model | HDX THOMAS 07-16 |
| Year | 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016 |
REACH COOLING 42-10452 Specifications
Product Attributes
| Core Height | 27 9/16 IN |
| Core Row Quantity | 2 |
| Core Width | 31 13/16 IN |
| Outlet Diameter | 2 1/2 IN |
| Core Thickness | 1.78 IN |
| Inlet Diameter | 2.5 IN |
| Core Thickness | 45.212 MM |
| Inlet Diameter | 64 MM |
| Frame Included | No |
| Outlet Diameter | 63.5 MM |
| Down Flow Or Cross Flow Type | Cross Flow |
| Tank Material | PA66-GF30 |
| Inlet Location | Upper left |
| Inlet Diameter | 63.5 mm |
| Core Thickness | 48 MM |
| Outlet Location | Lower Right |
| Transmission Oil Cooler Included | No |
| Core Height | 700.074 MM |
| Core Height | 700.1 MM |
| Core Width | 808 MM |
| Core Material | Aluminum |
| Core Width | 808.024 MM |
| Engine Oil Cooler Included | No |
| Outlet Diameter | 63.5 MM |
| Radiator Cap Included | No |
Additional Information
| Country of Origin (Primary) | CN |
| Warranty Special | 12 Months |
| UPC | 06941099904081 |
| VMRS Code | 042002001 |
| UNSPSC | 25174002 |
REACH COOLING 42-10452 Part Interchanges
| Brand | Part Number |
|---|---|
| Northern Radiator | 238621 |
| OEM | LT1049, VAB1003682, 1003682 |
| Serck | FLA001033 |
| Freightliner | 1003682, 1003682BS, 1050190, 1050190BR, 1050190BS, 1102418AS, 6212539, BHT4482 |
| Active Radiator Supply Company | 310083, 3100-83 |
| NAPA | NR4210452 |
| OSC | HD1049 |
| 1-800-Radiator | 2400249 |
| Lei Te | LT1049 |
| Superior Cooling Systems | 238621 |
REACH COOLING 42-10452 Fits Vehicles
- Thomas Saf-T-Liner (2007-2016)
REACH COOLING 42-10452 Cross References
We have 14 alternatives for the 42-10452 by REACH COOLING:
REACH COOLING 42-10452 Manufacturer Information
Founded in 1999, Reach Cooling® is a worldwide leader in the manufacture and distribution of aftermarket cooling products for light, medium, and heavy duty truck applications. Its fasting-growing division is within its medium and heavy duty truck part sector, offering more than 30 HD condensers, more than 50 HD charge air coolers, and more than 100 HD radiators. All these products are manufactured to meet the highest OE standards to fit some of the most popular US truck makes, including Peterbilt, Mack, International, Isuzu, GMC, Ford, and Freightliner. Headquartered in Miami, Florida, Reach Cooling is fully committed to providing customers with only the best products, most competitive prices, and exceptional service.
