DANA 600001056 - WING IN A BOX 15C RELUBE US
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
DANA part description
California Proposition 65 Warning
California Proposition 65 Warning
Specifications
| Brand | Spicer |
| Series | 15C |
| Material | Steel |
| Type | ReLube OEM |
| Slip (Mm) | 130.0000 |
| Slip (In) | 5.1180 |
| T | 23.0120 |
| Recommended Tube | 831600010-1900M |
| Note 1 | T Dim is used to determine the tubing length?he "T" Dim is the total length of an Assembled and Collapsed Driv... View all eshaft from mounting face to mounting face less the tubing length.View less |
| Note 2 | The tube inside diameter should be turned to 5.551" at a depth of .984" then radiused on inside each end befor... View all e installing the tube fittings into the tube.View less |
| VMRS | 024002069 |
| Package Type | EACH |
| Package Qty | 1 |
| Weight | 90.72 LB |
| Country of Origin | Italy |
Product Attributes
| Series | 15C |
| Material | Steel |
| Type | ReLube OEM |
| Slip (In) | 5.1180 IN |
| Slip (Mm) | 130.0000 MM |
| Note 1 | T Dim is used to determine the tubing length?he "T" Dim is the total length of an Assembled and Collapsed Driveshaft from mounting face to mounting face less the tubing length. |
| Recommended Tube | 831600010-1900M |
| T | 23.0120 |
| Note 2 | The tube inside diameter should be turned to 5.551" at a depth of .984" then radiused on inside each end before installing the tube fittings into the tube. |
Additional Information
| Country of Origin (Primary) | IT |
| UPC | 00023913437459 |
| VMRS Code | 024002069 |
Part Interchanges
Dana Holding Corporation® is an internationally known company specializing in drivetrain and e-Propulsion systems. It conceptualizes, manufactures, and supplies energy-management and power- and conveyance solutions for the present-day and future vehicles and trucks. With its over 115 years of industry experience and innovation, and despite several turbulences the automotive and trucking industry has been through, Dana has managed to take the lead in revolutionary technological inventions. Dana Holding Corporation comprises different world-renowned brands catering to various market segments. These include SPICER Drivetrain Systems, VICTOR REINZ Sealing Products, LONG Thermal Products, BREVINI Motion Systems, GRAZIANO High-Performance Transmissions, FAIRFIELD Custom Gears and Drives, and a lot more.
