Centric 123.99024 - C-Tek Standard Brake Drum
$11349
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
Product Attributes
| Misc Holes [cntrc] | 3 |
| Weight [cntrc] Kgs | 10.886 |
| Weight [cntrc] Lbs | 23.950 |
| Bolt Circle Diameter [cntrc] Mm | 120.000 |
| Bolt Circle Diameter [cntrc] In | 4.724 |
| Hub Hole / Register [cntrc] Mm | 76.000 |
| Hub Hole / Register [cntrc] In | 2.992 |
| Height [cntrc] Mm | 95.500 |
| Height [cntrc] In | 3.760 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 296.500 MM |
| Maximum Brake Diameter (Discard) | 11.673 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 16.600 MM |
| Mounting Hole Diameter | 0.654 IN |
| Nominal Drum Diameter | 11.614 IN |
| Nominal Drum Diameter | 295.000 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 889590001822 |
Part Interchanges
Fits Vehicles
- Volkswagen Amarok (2011-2017)
