Centric 226.20025 - C-Tek Standard Slotted Brake Rotor
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
CENTRIC part description
Product Description
C-Tek Standard Slotted Brake Rotor
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. G11 metallurgy. Slotted for increased bite; improved looks and better performance
Product Attributes
| Misc Holes [cntrc] | 5 |
| Weight [cntrc] Lbs | 33.750 |
| Weight [cntrc] Kgs | 15.340 |
| Vane Style [cntrc] | Curved |
| Product Grade [cntrc] | Standard |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Disc Mounting [cntrc] | Floating |
| Discard Thickness | 34.000 MM |
| Discard Thickness | 1.339 IN |
| Nominal Thickness | 1.417 IN |
| Nominal Thickness | 36.000 MM |
| Overall Height | 63.500 MM |
| Overall Height | 2.500 IN |
| Outside Diameter | 400.000 MM |
| Outside Diameter | 15.748 IN |
| ABS Tone Ring Included | No |
| Surface Type | Slotted |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 2.795 IN |
| Center Hole Diameter | 71.000 MM |
| Mounting Bolt Hole Circle Diameter | 108.000 MM |
| Mounting Bolt Hole Circle Diameter | 4.252 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 14.200 MM |
| Stud/Lug Hole Diameter | 0.559 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890380108 |
Part Interchanges
Fits Vehicles
- Jaguar XKR-S (2012, 2014)
- Jaguar XKR (2008-2012, 2014-2015)
