Name: National Seals 1176 National 1176 Differential Pinion Seal
SKU: 1176
Price: 24.25 USD
Availability: OutOfStock

NATIONAL SEALS part description

Product Description

Differential Pinion Seal

Application Summary

1971-1985 Toyota Celica (Rear Outer) (Qualifier: with 6.7 (in) Ring Gear, with Toyota Axle); 1968-1987 Toyota Corolla (Rear Outer) (Qualifier: with 5.7 (in) Ring Gear, with Toyota Axle, with 6.38 (in) Ring Gear, with 6.25 (in) Ring Gear, with 6.7 (in) Ring Gear, with 6.62 (in) Ring Gear); 1967-1982 Toyota Corona (Rear Outer) (Qualifier: with 6.62 (in) Ring Gear, with Toyota Axle, with 6.7 (in) Ring Gear); 1971-1973 Toyota Carina (Rear Outer) (Qualifier: with 6.62 (in) Ring Gear, with Toyota Axle)

Features & Benefits

Design type: spring loaded; multi-lip
Temperature range: -20°F to 300°F / -29°C to 49°C
Temperature range: -20degF to 300degF / -29degC to 49degC
Resistance to EP lubricants
Low swell in hydrocarbon fluids
Delivers quality and reliable performance for every type of repair

Product Attributes

Inside Diameter	1.496 IN
Inside Diameter	38.000 MM
Outside Diameter	2.570 IN
Outside Diameter	65.270 MM
Width	0.472 in
Width	12.000 MM
Material	Polyacrylate
Part Description	Oil Seal
Series	1000
Thickness	0.472 IN
Thickness	12.000 MM
Type	#
Unit of Dimension	Metric
Housing Bore	2.559 IN
Housing Bore	65.000 MM
Overall Width with Side Lip	19.000 MM
Overall Width with Side Lip	0.748 in
Shaft Diameter	1.496 IN
Shaft Diameter	38.000 MM
Shaft Diameter	38.000 MM
Grade Type	Premium

Additional Information

Country of Origin (Primary)	TW
Harmonized Tariff Code (Schedule B)	4016931020
Harmonized Tariff Code (HTS)	4016931020
Canadian Harmonizing Tariff Code	4016930000
UPC	00724956043255

Part Interchanges

Fits Vehicles

Toyota Carina (1971-1973)
Toyota Corona (1967-1982)
Toyota Corolla (1968-1987)
Toyota Celica (1971-1985)
