(888) 312-8812 Login SignupMERITOR FS9105 AIR SPRING
Tap to view 5 more
MSRP: $517.74
$30299
Save $214.75
Limited availability at this price!
In Stock
Get it by Friday, Sep 4
MERITOR FS9105 Part Description
| Aftermarket Extended Warranty - General | 3 Years / 300K Miles |
| Application | Service Assembly W01-358-0725; Hendrickson Trailer S1245; Granning 5065; Ridewell 1003589105C; Watson & Chalin AS-0015 |
| Bead Plate Diameter Bottom | 9.75 in. |
| Bead Plate Diameter Top | 9.00 in. |
| Collapsed Height | 6.00 in. |
| Convoluted Style | 1T Reversible Sleeve |
| Max. Height | 15.00 in. |
| Part Diameter | 10.12 in. |
| Piston Height | 3.75 in. |
| Stud Configuration-Bottom | 4 |
| Stud Configuration-Top | 2 |
| Stud Mount-Bottom Flat | Flat |
| Stud Mount-Top Flat | Stud |
| VMRS Code | 016-008-000 |
Meritor Air Suspension Spring
Meritor air suspension spring protects tractors and trailers from road shocks and keep your ride a comfortable one. This aftermarket air spring covers a wide range of OEM specifications at affordable prices.
Features & Benefits
- Lightweight, high-strength pistons with support washers provide exceptional strength and durability
- Made of premium-grade steel and aluminum with electrostatic coating for oxidation resistance
- Special chromium coating on bead plate protects against rust, corrosive chemicals, and harsh operating environments
MERITOR FS9105 Specifications
Product Attributes
| Aftermarket Extended Warranty - General | 3 Years / 300K Miles |
| Application | Service Assembly W01-358-0725; Hendrickson Trailer S1245; Granning 5065; Ridewell 1003589105C; Watson & Chalin AS-0015 |
| Bead Plate Diameter Bottom | 9.75 in. |
| Bead Plate Diameter Top | 9.00 in. |
| Brand | Meritor Genuine |
| Collapsed Height | 6.00 in. |
| Convoluted Style | 1T Reversible Sleeve |
| Max. Height | 15.00 in. |
| Pallet Quantity | 16 |
| Part Diameter | 10.12 in. |
| Piston Height | 3.75 in. |
| Product Category | Genuine OE Product |
| Stud Configuration-bottom | 04 |
| Stud Configuration-top | 02 |
| Stud Mount-bottom Flat | Flat |
| Stud Mount-top Flat | Stud |
| Weight | 12.88 |
MERITOR FS9105 Cross References
| Brand | Part Number |
|---|---|
| RFS9105, JL7Z7831113FD | |
| BWP | M3516 |
| CONTITECH | 91012A319, 91012P319 |
| DAYTON PARTS BATCO | 3529105 |
| FIRESTONE | W013589105, 1T15M2, 9105 |
| FLAGG | 8319 |
| GOODYEAR | 1R12132, 1R12152 |
| HALDEX | CS112132 |
| HENDRICKSON | 9105 |
| HENDRICKSON TURNER | B1245, S1245 |
| NEWAY | AR13155FG, 57009105, 90557038 |
| PAGE SUSP. | 1090276 |
| PAGE SUSPENSION | 1090276 |
| RIDEWELL | S570C, 1003589105C |
| WATSON CHALIN | AS0015 |
| WORLD AMERICAN | WA01-9105C |
