(888) 312-8812 Login SignupMERITOR FS9069 Air Suspension Spring, 9.50 in. Bead Plate Diameter Bottom, 9.00 in. Bead Plate Diameter Top
Tap to view 5 more
MSRP: $405.29
$18199
Save $223.30
Limited availability at this price!
In Stock
Get it by Wednesday, Sep 2
MERITOR FS9069 Part Description
Manufacturer
Product Description
Firestone Air Spring
Meritor Firestone Air Suspension Spring
Renew air-ride load support with the Meritor Firestone Air Suspension Spring. This genuine OE air spring uses a 9.00-inch top bead plate diameter and 9.50-inch bottom bead plate diameter for suspension service. Its 14.09-pound build gives the air suspension a complete spring unit rather than a loose fitting, valve, or mounting plate. The Meritor FS9069 is the better selection when the air spring position needs a Firestone-built replacement with known bead plate dimensions.
| Aftermarket Extended Warranty - General | 3 Years / 300K Miles |
| Application | Peterbilt 03-02456; Peterbilt 03-04759; Peterbilt 03-01649; Peterbilt 03-06746; Peterbilt 03-07112; Peterbilt 03-02038 (Air-Trac); Mfg. SV# Peterbilt 03-10042 |
| Bead Plate Diameter Bottom | 9.50 in. |
| Bead Plate Diameter Top | 9.00 in. |
| Collapsed Height | 7.50 in. |
| Convoluted Style | 1T Reversible Sleeve |
| Max. Height | 18.00 in. |
| Part Diameter | 10.12 in. |
| Piston Height | 4.75 in. |
| Stud Configuration-Bottom | 1 |
| Stud Configuration-Top | 3 |
| Stud Mount-Bottom Flat | Stud |
| Stud Mount-Top Flat | Flat |
| VMRS Code | 016-008-000 |
Meritor Air Suspension Spring
Meritor air suspension spring protects tractors and trailers from road shocks and keep your ride a comfortable one. This aftermarket air spring covers a wide range of OEM specifications at affordable prices.
Features & Benefits
- Lightweight, high-strength pistons with support washers provide exceptional strength and durability
- Made of premium-grade steel and aluminum with electrostatic coating for oxidation resistance
- Special chromium coating on bead plate protects against rust, corrosive chemicals, and harsh operating environments
- Restores ride height control when the original spring leaks or sags
MERITOR FS9069 Specifications
Product Attributes
| Aftermarket Extended Warranty - General | 3 Years / 300K Miles |
| Application | Peterbilt 03-02456; Peterbilt 03-04759; Peterbilt 03-01649; Peterbilt 03-06746; Peterbilt 03-07112; Peterbilt 03-02038 (Air-Trac); Mfg. SV# Peterbilt 03-10042 |
| Bead Plate Diameter Bottom | 9.50 in. |
| Bead Plate Diameter Top | 9.00 in. |
| Brand | Meritor |
| Collapsed Height | 7.50 in. |
| Convoluted Style | 1T Reversible Sleeve |
| Max. Height | 18.00 in. |
| Pallet Quantity | 32 |
| Part Diameter | 10.12 in. |
| Piston Height | 4.75 in. |
| Product Category | Genuine OE Product |
| Stud Configuration-bottom | 01 |
| Stud Configuration-top | 03 |
| Stud Mount-bottom Flat | Stud |
| Stud Mount-top Flat | Flat |
| Weight | 14.09 |
| Air Spring Type | Reversible Sleeve |
| Max Height | 18.00 in. |
MERITOR FS9069 Cross References
| Brand | Part Number |
|---|---|
| TDAFS9069, W701242S437 | |
| Automann | 566CT64274, 566ER9069, AB1DK23I9069, AB1DK23IA312 |
| BWP | M3512 |
| CONTITECH | 91014P312 |
| Continental-ContiTech | 64274, 91014P312 |
| DAYTON PARTS BATCO | 3529069, 1R12069, 1R12669, 1R12676 |
| FIRESTONE | W013589069, 1T15M4, 9069 |
| FLAGG | 8312 |
| Firestone Ride-Rite | 1T15M4, 9069, W013589069 |
| Ford | 1T15M4 |
| GOODYEAR | 1R12069, 1R12669 |
| HALDEX | CS112069 |
| HENDRICKSON | S13031, 9069 |
| International | 554764C1 |
| NEW LIFE/FLEETCRAFT | 1R12069 |
| NEWAY | 57000709, 57009069 |
| PARTS AMERICA | 9069 |
| POWER EQUIPMENT -PDC | 9069 |
| PROVINCIAL WHSE -CAN | M6506, M6906 |
| Peterbilt | 301649, 302038, 302456, 304759, 307112, 306746, 310042 |
| RIDEWELL | 1003589069C |
| Ridewell Corp | 1003589069C |
| S AND G | AS5049069 |
| SIRCO BRAKE | AS9069 |
| TW HEAVY VEHICLE PTS | 1R12069 |
| Trailmobile | 3057000709, GY1R12069 |
| UCF AMERICA | AB1R12069 |
| Volvo | 3130497 |
| WATSON CHALIN | AS0077 |
| WORLD AMERICAN | WA01-9069C |
