MERITOR M85933 Part Description
Manufacturer
Product Description
Shock Absorber
Meritor Suspension Shock Absorber
The Meritor Suspension Shock Absorber dampens harsh road impacts to provide steady control over your commercial truck chassis. Designed with an extended length of eighteen inches and a generous stroke, this unit absorbs heavy axle travel effortlessly. Annoying cabin sway and tire hopping disappear instantly when you install the Meritor M85933 on your rig. Keeping your suspension system properly controlled protects fragile freight and reduces operator fatigue during long shifts.
| Body Diameter (in.) | 2.38 in. |
| Body Diameter (mm) | 60.5 mm |
| Bore (in.) | 1.63 in. |
| Bore (mm) | 41 mm |
| Collapsed Length (in.) | 12.70 in. |
| Collapsed Length (mm) | 322.6 mm |
| Dust Shield Diameter (in.) | 2.75 in. |
| Dust Shield Diameter (mm) | 69.9 mm |
| Extended Length (in.) | 18.24 in. |
| Extended Length (mm) | 463.3 mm |
| Family Code | 41FCMD |
| Hydraulic Stop | Yes |
| Stroke | 140.7 mm |
| Stroke Inch | 5.54 in. |
| Type | Standard |
| VMRS Code | 016-008-003 |
Meritor Shock Absorber
Meritor shock absorber is designed for exceptional day-in and day-out performance for trucks, trailers, and other types of heavy duty commercial vehicles. This shock provides better ride comfort, operational control, and cargo protection than what the competition has to offer.
Features & Benefits
- Advanced gas cell system reduces oil cavitation from heavy use, maximizing damping efficiency and extending shock life
- Hardened piston rod with polished chrome coating for superior corrosion resistance
- Made of premium materials to ensure reliable performance even under extreme conditions
- Mounting eyelet designs slide onto existing chassis brackets easily for fast changeouts
MERITOR M85933 Specifications
Product Attributes
| Body Diameter (in.) | 2.38 in. |
| Body Diameter (mm) | 60.5 mm |
| Bore (in.) | 1.57 in. |
| Bore (MM) | 40 mm |
| Brand | Meritor |
| Collapsed Length (in.) | 12.95 in. |
| Collapsed Length (mm) | 329 mm |
| Dust Shield Diameter (in.) | 2.75 in. |
| Dust Shield Diameter (mm) | 70 mm |
| Extended Length (in.) | 18.35 in. |
| Extended Length (mm) | 466 mm |
| Family Code | 41FCMD |
| Hydraulic Stop | Yes |
| Pallet Quantity | 198 |
| Stroke | 137 mm |
| Stroke Inch | 5.39 in. |
| Type | Standard |
| Weight | 7.60 |
| Body Diameter | 2.38 in. |
| Compressed Length | 12.95 in. |
| Extended Length | 18.35 in. |
| Dust Shield Diameter | 2.75 in. |
| Shock Stroke | 137 mm |
| Shock Absorber Bore Size | 1.57 in. |
| Type | Standard |
MERITOR M85933 Cross References
| Brand | Part Number |
|---|---|
| 85933, E14009, R3014009, 65497M, GAB85933, TDAM85933, 1000SA5933, 14QK422M, 20485633, 315415, 64838001, 64838002, 64838003, 65497, AMS65497, HS85933, MERM85933, MO65497, RCSA5933, SA5933 | |
| AUTOMANN | A85933 |
| GABRIEL | 85933, 89454 |
| HENDRICKSON | 64838-002, 64838-001 |
| HENDRICKSON TRUCK SUSPENSION SYSTEMS | 64838-001, 64838-002 |
| Hendrickson | 64838003L |
| MACK | 64838-002, 14QK-422M, 14QK422M |
| MERITOR | M89454 |
| MONROE | 65497 |
| VOLVO | 20485633, 64838-001, 64838-002 |
MERITOR M85933 Customer Reviews
No reviews yet
Be the first to review this product!
MERITOR M85933 Manufacturer Information
Meritor®, whose roots could be traced back to 1909, is backed by over 100 years of industry experience plus a massive portfolio of products for various industries. In 1998, it made several acquisitions, including Volvo Trucks' heavy vehicle manufacturing operation in Sweden, Euclid Industries, and Lucas Varity's Heavy Vehicle Braking Systems division. Such investments solidify Meritor's position as the leading global supplier of brakes, axles, drivelines, transmissions, suspensions, tire inflations systems, and a whole lot of parts, hardware, and accessories for the automotive, truck, trailer, rail cars, bus and coach, and many other applications. Its "Run with the Bull" global brand identity further strengthens its commitment to provide the industry with durable products, unparalleled service and support, and continuous innovation.
MERITOR M85933 Questions & Answers
No questions yet
Be the first to ask a question about this product!
