30010071 by HALDEX - Automatic Brake Adjuster (ABA) - Rear Brake, 5.25 in. Arm Length, 1.5 in. (Spline Diameter), 10 (Spline Quantity)

Haldex 30010071 - Automatic Brake Adjuster (ABA) - Rear Brake, 5.25 in. Arm Length, 1.5 in. (Spline Diameter), 10 (Spline Quantity)

Part Number
30010071
Manufacturer
HALDEX
Description

Automatic Brake Adjuster (ABA) - Rear Brake, 5.25 in. Arm Length, 1.5 in. (Spline Diameter), 10 (Spline Quantity)

details

NO STOCK AVAILABLE

We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.

Sometimes we may have similar parts for sale, click the button below to see if anything matches.

Search Alternatives

HALDEX part description

Product Description

Auto Brake Adjuster (ABA), Transit/Severe Duty, Arm Length 5-1/4" Offset 5/8"

Application Summary

TRANSIT AA1. Opposite Side Brake Adjuster: 30010072

Features & Benefits

  • Covers more applications than competing adjusters in the market
  • Compatible with clevises from major OE and aftermarket brands
  • Easily accessible hex nut for easy adjustment and maintenance
  • Specially-crafted wormshaft provides added resistance against fatigue
  • Heavy duty gaskets and O-rings seal out moisture and contaminants
  • Fully-sealed design protects linkages against the elements for added durability
  • Helps prevent uneven tire and brake wear for added savings on maintenance and operating expenses
  • Heat-treated steel alloy internal gears provide increased strength and wear resistance

Haldex Transit ABA Service Kit

Improve your ride’s stopping performance with the Haldex transit ABA service kit. This helps improve handling in various driving conditions and is heat-treated for added strength and corrosion resistance.

Product Attributes

Anchor Bracket Style Clamp
Arm Hole Diameter 1/2 in.
Arm Length 5-1/4 in.
Body Angle 22.5 DD
Freight Class 70
Grease Fitting Location 242 DD
Grease Fitting Type 65°
Location Rear
Offset 0.63 in.
Pin Diameter 1/2 in.
Recommended Bracket Number 42710217
Spline Diameter 1-1/2 in.
Spline Quantity 10

Additional Information

Country of Origin (Primary) US
Harmonized Tariff Code (Schedule B) 8708305090
Harmonized Tariff Code (HTS) 8708305090
Remanufactured Part N
Warranty Distance 100000
Warranty Distance UOM MI
Warranty Special 72 MO, 1 MIL MI=Haldex ABA/SABA (409 Part Number Prefix)(1), 36 MO, Unlimited MI=Haldex ABA (NL/429 Part Number Prefix)(1). 24 MO, 200K MI=Haldex ABA(8). 24 MO, 100K MI=Haldex ABA/S-ABA(3) & Non-Haldex ABA. 12 MO, 100K MI=Haldex ABA(9). See L20221W.pdf
Warranty Time 12
Warranty Time UOM MO
UPC 00767653200453
VMRS Code 013002035

Part Interchanges

Haldex® is a Sweden-based manufacturer specializing in brake and air suspension systems for heavy duty vehicles. Its product line consists of brake components for wheel ends, including disc brakes, brake adjusters, and actuators. It also offers air control products such as compressed air dryers, valves, ABS, and EBS. All these Haldex products are designed with safety and efficient operation in mind, cutting down on potential hazards and maintenance costs in the long run. Today, Haldex runs manufacturing and R&D facilities in 19 countries across four continents. It is dedicated to producing high-quality brake and suspension parts for its customers all around the world as well as developing new technologies for the future.
