Gates G35210-0808X - Dual Seat Female JIC 37/SAE 45 Flare Swivel - Steel (C5E Hose)
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
GATES part description
Product Description
Dual Seat Female JIC 37/SAE 45 Flare Swivel - Steel (C5E Hose)
Features & Benefits
- Designed to perform with Gates C5E Hose
- Zinc-plated carbon steel
- Meets DOT FMVSS 106-74 Type AII
Product Attributes
| Coupling Description | Field Attach C5E Dual Seat Female JIC 37/SAE 45 Flare Swivel - Steel |
| Industrial Description | 8C5E-8RFJSX XBULK |
| Thread Size | 3/4-16 |
| Inside Diameter | .406 IN |
| Hydraulic Hose Recommendation | Gates C5E |
| Stem Hex Size | .875 IN |
| Nut Hex Size | .875 IN |
| Cut-Off Length | 1.45 IN |
| Length | 2.45 IN |
| Inside Diameter | 10.3 MM |
| Cut-Off Length | 36.8 MM |
| Length | 62.2 MM |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 7326908688 |
| UPC | 00072053848274 |
| VMRS Code | 059032012 |
| UNSPSC | 31163000 |
Part Interchanges
