Gates G25230-0406 - 4G-6FFORX
$1399
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
GATES part description
Product Description
Female Flat-Face O-Ring Swivel (MegaCrimp)
Features & Benefits
- Robust "bite-the-wire" crimp
- Robust “bite-the-wire” crimp
- Tested to an industry-leading 1,000,000 impulse cycles
- Simplifies inventory management
- Environmentally-friendly TuffCoat plating for 347 percent better corrosion resistance than the SAE Standard
- Popular thread styles also available with TuffCoat Xtreme plating for 583 percent better corrosion resistance than the SAE Standard
Product Attributes
| Coupling Description | MegaCrimp Female Flat-Face O-Ring Swivel |
| Industrial Description | 4G-6FFORX |
| Thread Size | 11/16-16 |
| Inside Diameter | .25 IN |
| Hydraulic Hose Recommendation | Can Accommodate Various Hose Outside Diameters on Both One-Wire & Two-Wire Braid Hydraulic Hose |
| Stem Hex Size | 15 MM |
| Nut Hex Size | 22 MM |
| Cut-Off Length | .99 IN |
| Length | 2.01 IN |
| Seal Type | O-Ring |
| O-Ring Location | Flat Face O-Ring |
| Gender | Female |
| Bent Tube Angle | Straight |
| Swivel | Yes |
| Bulkhead | No |
| Inside Diameter | 6.4 MM |
| Cut-Off Length | 25.1 MM |
| Length | 51.1 MM |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 8412909015 |
| UPC | 00072053323627 |
| VMRS Code | 059032012 |
| UNSPSC | 31163000 |
Part Interchanges
- Aeroquip 1AA6FR4
- Parker 1JC43-06-04
- Parker 1JC43-6-4
- Parker 1JS43-06-04
- Parker 1JS43-6-4
- Parker 1JSHY-6-4
- Dayco 101324
- Dayco 108711
- Dayco 151711
- Weatherhead 04EES66
- Weatherhead 04ES66
- Weatherhead 04US66
- Weatherhead 04ZS66
- Caterpillar 124-2113
- Goodyear 13700-0406
- Goodyear 14700-0406
- Goodyear B2-OFFX-0406
- Goodyear UC-OFFX-0406
- NAPA G25230-0406
- Kurt Hydraulics FFX-04-06
