Gates G25170-0812 - 8G-12FJX
$2649
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
GATES part description
Product Description
Female JIC 37 Flare Swivel (MegaCrimp)
Features & Benefits
- Robust "bite-the-wire" crimp
- Robust “bite-the-wire” crimp
- Tested to an industry-leading 1 million impulse cycles
- Simplifies inventory management
- Environmentally-friendly TuffCoat plating for 347 percent better corrosion resistance SAE Standard
- Popular thread styles also available with TuffCoat Xtreme plating for 583 percent better corrosion resistance than the SAE standard
Product Attributes
| Coupling Description | MegaCrimp Female JIC 37 Flare Swivel |
| Industrial Description | 8G-12FJX |
| Thread Size | 1 1/16-12 |
| Inside Diameter | .5 IN |
| Hydraulic Hose Recommendation | Can Accommodate Various Hose Outside Diameters on Both One-Wire & Two-Wire Braid Hydraulic Hose |
| Stem Hex Size | 22 MM |
| Nut Hex Size | 32 MM |
| Cut-Off Length | 1.67 IN |
| Length | 3.06 IN |
| Seal Type | Mated Angle |
| Nose Seat Type | Standard |
| Mating Angle | 37 |
| Gender | Female |
| Bent Tube Angle | Straight |
| Swivel | Yes |
| Inside Diameter | 12.7 MM |
| Cut-Off Length | 42.5 MM |
| Length | 77.7 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8412909015 |
| Country of Origin (Primary) | US |
| UPC | 00072053323108 |
| VMRS Code | 059032012 |
| UNSPSC | 31163000 |
Part Interchanges
- Aeroquip 1AA12FJ8
- Aeroquip FJ9122-1208S
- Parker 10643-12-08
- Parker 10643-12-8
- Parker 106HY-12-8
- Dayco 108077
- Dayco 151077
- Weatherhead 08U612
- Weatherhead 08Z612
- Caterpillar 124-1963
- Goodyear 13400-0812
- Goodyear 14400-0812
- Goodyear B2-JCFX-0812
- Goodyear T8-JCFX-0812
- NAPA G25170-0812
- Kurt Hydraulics FJX-08-12
