70601 by GATES - Global G1 1-Wire Braid Hose - SAE 100R1 Type S

Gates 70601 - Global G1 1-Wire Braid Hose - SAE 100R1 Type S

Part Number
70601
Manufacturer
GATES
Description

Global G1 1-Wire Braid Hose - SAE 100R1 Type S

details

$3,461.15

Package Price for 385 Units
@ $8.99 per unit

In stock

limited availability at this price!

New! No hassle Return Policy details
Free Economy shipping on orders over $499 details
Orders placed over the weekend will ship the following business day
Get it by Thursday, Sep 25
Pay over 3-12 months with Affirm Logo. Learn more

GATES part description

Product Description

Global G1 1-Wire Braid Hose - SAE 100R1 Type S

Features & Benefits

  • Use with Field Attachable Type T [G27 Series], GlobalSpiral [G20 Series], GlobalSpiral Plus [G22 Series], MegaCrimp [G25 Series], Power Crimp or Stainless Steel Braid Couplings [G17 Series]
  • Meets Flame Resistance Acceptance Designation MSHA 2G
  • Temperature Range: -40 Deg. F to +212 Deg. F (-40 Deg. C to +100 Deg. C)

Product Attributes

Product Type Global G1 1-Wire Braid Hose - SAE 100R1 Type AT
Industrial Description 6G1XREEL
Type Hydraulic Hose
Hose Pressure Description Medium Pressure
Maximum Working Pressure 2600 PS
Burst Pressure 10400 PS
Temperature Rating -40 Deg. F to +212 Deg. F (-40 Deg. C to +100 Deg. C)
Length 385 FT
9941 6
Inside Diameter .375 IN
Outside Diameter .68 IN
9879 5
Tube Description Black, Oil-Resistant, Synthetic Rubber
Hose Material Nitrile - Type C
Reinforcement Material One Braid, High-Tensile Steel Wire
Cover Material Synthetic Rubber - Nitrile/PVC - Type C2
Cover Type Type C2 - Flame, Oil & Abrasion Resistant
Cover Color Black
9856 Field Attachable T, GlobalSpiral, MegaCrimp, Stainless Steel B
9453 100R1
9954 853 1SN
9953 1436 1SN R1

Additional Information

Harmonized Tariff Code (Schedule B) 4009210000
Country of Origin (Primary) MX
UPC 00072053210989
VMRS Code 059032029
UNSPSC 40142020

Part Interchanges

California Proposition 65 Warning California residents see Prop 65 Warning(s)
