WABCO 4801030110 - Electronic Brake Control Module - EBS Axle Modulator 2 Channel, Gen1
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
WABCO part description
Product Attributes
| Weight | 12.948 |
| Max. operating pressure | 145.0 psi |
| Distance Between Holes | 100 mm |
| Type | 4 x 2 |
| Temperature Range | -40°C to +80°C |
| Application | 4x2 |
| Size | 229 x 179 x 200 |
| Electrical connection | Bayonet DIN 72585 1A-4.1-Sn/K2 |
| Port thread 3 | Integrated Silencer |
| Port thread 21 | M22 x 1.5 JED - 388 |
| Port thread 22 | M22 x 1.5 JED - 388 |
| Port thread 12 | M22 x 1.5 JED - 388 |
| Mounting | 2x M12 x 1.5 |
| Port thread 23 | M16 x 1.5 JED - 388 |
| Voltage | 24 V |
| Rated current | 5 A |
| Port Thread 13 | M22 x 1.5 JED-388 |
| Port thread 11 | M22 x 1.5 JED - 388 |
| Protection class | IP 66 / IP 69 K |
| Calculated Volume (dm³) | 8.1982 |
WABCO 4801030110 Cross Reference
We have 6 alternatives for the 4801030110 by WABCO:
Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
