WABCO 9254610520 - Air Brake Spring Brake Cylinder Assembly - Tristop-Cylinder Disc G-24/24
$61199
14 day lead time
. Learn more
WABCO part description
Tristop-Cylinder Disc, G-24/24
Product Attributes
| Max. operating pressure | 10.2/8.5 bar |
| Push-Rod Length | 15 mm |
| Weight | 17.926 |
| Distance between bolts | 120.6 mm |
| Calculated Volume (dm³) | 16.648 |
| Type | 24/24 |
| Temperature Range | -40°C to +80°C |
| Size | 406 x 202 x 203 |
| Push-rod thread | Ball R8 |
| Total Length | 259.0 mm |
| Stroke | 64/64 mm |
| Port threads | M16 x 1.5 |
| Type Of Operation | Disc |
| Port thread 12 | M16 x 1.5 |
| Port thread 11 | M16 x 1.5 |
| Return-Spring Force | 220 N |
| Output Force M | 9100 N |
| Bolt Lengths | 43.0 mm |
| Bolt Threads | M16 x 1.5 |
| Release Pressure | 5.1 bar |
WABCO 9254610520 Cross Reference
We have 1 alternatives for the 9254610520 by WABCO:
Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
