WABCO 9254644520 - Air Brake Spring Brake Cylinder Assembly - Tristop Cylinder Disc G-16/16
$88649
14 day lead time
Pay over 3-12 months with
. Learn more
. Learn more
WABCO part description
Tristop Cylinder Disc, G-16/16
Product Attributes
| Distance between bolts | 120.6 mm |
| Max. operating pressure | 147.94 / 123.28 psi |
| Weight | 15.49 |
| Calculated Volume (dm³) | 13.026 |
| Push-Rod Length | 15 mm |
| Return-Spring Force | 220 N |
| Size | 383 x 179 x 190 |
| Type | 16/16 IBV |
| Output Force M | 6150 N |
| Total Length | 253.0 mm |
| Bolt Threads | M16 x 1.5 |
| Port thread 11 | M16 x 1.5 |
| Release Pressure | 5.1 bar |
| Stroke | 57/57 mm |
| Temperature Range | -40°C to +80°C |
| Bolt Lengths | 43.0 mm |
| Type Of Operation | Disc |
| Port threads | M16 x 1.5 |
| Push-rod thread | Ball R8 |
Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
