DANA SPICER 2-4-4341 Part Description
Manufacturer
| Spline OD | 1.146 |
| No of Splines | 26 I |
| R Hub Dia | 1.552 |
| Q Len Thru Hole | 1.5 |
| S CL to End | 3 |
| CBore Depth | 0 |
| Style | CV |
Dana Holding Corporation End Yoke
The Dana Holding Corporation end yoke efficiently links the transmission to the drive axle. Installing this component addresses the signs of a failing yoke and u-joint, which include squeaking noise when moving forward or reverse, vibration when running at high speeds, and many others.
Features & Benefits
- Durably engineered to improve a vehicle or a construction equipment’s performance and efficiency
- Integrates cutting-edge technologies to make a vehicle or machine more productive on the job site
- Meets strict quality standards for dependable functionality even under the harshest operating environment
- Backed by the company’s over 115 years of innovation and technological revolutions
DANA SPICER 2-4-4341 Specifications
Product Attributes
| Series | 1310 |
| Material | Steel |
| Spline Count | 26 |
| Type | Splined Hole |
| Hub Diameter R | 1.552 IN |
| Involute Spline | I |
| Length Thru Hole Q | 1.500 IN |
| Outside Yoke Dimension (In) E | 3.219 IN |
| Yoke Bearing Dimension (In) D | 1.062 IN |
| Yoke Style | CV |
| Major Diameter | 1.146 IN |
| C/L To End Hub S | 3.000 IN |
| Joint Angle #1 | 13 |
Additional Information
| Country of Origin (Primary) | IN |
| Harmonized Tariff Code (Schedule B) | 8708990000 |
| Harmonized Tariff Code (HTS) | 8708990000 |
| UPC | 00023913236762 |
| VMRS Code | 024001003 |
DANA SPICER 2-4-4341 Cross References
| Brand | Part Number |
|---|---|
| Daimler Truck North America | SP 2 4 4341HP |
| Dana Commercial Vehicle Service Parts | 2104-244341 |
| Freightliner | SP 2 4 4341HP |
| International Harvester (IHC) | 244341, D244341, E244341 |
| Mack | 2104-244341 |
| NEAPCO | N2-4-4341 |
| Navistar | 244341, D244341, DS244341, E244341 |
| Volvo | 2104-244341, SP 244341 |
