DELPHI TC8311 Control Arm and Ball Joint Assembly

$111.99

Limited availability at this price!

In Stock

Get it by Friday, Dec 19
No Hassle Return Policy Details
Free Economy shipping on orders over $499 details
Orders placed before 2pm EST will ship same day

DELPHI TC8311 Part Description

Manufacturer

DELPHI

Product Description

Control Arm and Ball Joint Assembly

Control Arm and Ball Joint Assembly

DELPHI TC8311 Specifications

Product Attributes

Bushing Color Black
Finish Painted
Pre-Greased Yes
Bushings Included Yes
Dust Boot Included Yes
Ball Joint Mounting Type Machined
Ball Joint Stud Type Grooved
Ball Joint Included Yes
Control Arm Construction Casting/Forged
Control Arm Material Cast Iron
Mounting Hardware Included No
Grade Type Premium
Boot Material Chloroprene Rubber (CR)
Adjustable No
Greaseable No
Control Arm Maximum Width 255.00 MM
Control Arm Color Black
Ball Joint Stud Length 70.50 MM
Control Arm Maximum Length 310.00 MM
Boot Color Black
Steering Type Power
Bearing Material Plastic
Bushing Material Rubber
Dust Boot Material Chloroprene Rubber (CR)
Distance Between Bushings 228.00 MM
Bushing Inside Diameter 12.50 MM
Bushing Length 49.50 MM
Position(s) Rear Left Upper
Control Arm Maximum Width 10.039 IN
Ball Joint Stud Length 2.776 IN
Control Arm Maximum Length 12.205 IN
Distance Between Bushings 8.976 IN
Bushing Inside Diameter 0.492 IN
Bushing Length 1.949 IN

Additional Information

Country of Origin (Primary) CN
Harmonized Tariff Code (Schedule B) 8708807000
Harmonized Tariff Code (HTS) 8708806590
Warranty Special Limited Lifetime
Warranty Special UOM LF
UPC 00689604390924
VMRS Code 016008121
UNSPSC 25172013

DELPHI TC8311 Part Interchanges

Brand Part Number
N/A 20252 AJ03A, 20252 SC010

DELPHI TC8311 Fits Vehicles

  • Subaru Outback (2010-2019)

DELPHI TC8311 Manufacturer Information

Delphi® is committed to making a difference. With a global network of more than 2,400 service centers and a presence in over 150 countries, Delphi Technologies delivers OE-specific aftermarket parts and software solutions for a wide range of passenger vehicles, light and medium commercial vehicles, heavy-duty truck and commercial vehicles, as well as agricultural, marine, and industrial equipment. The company’s comprehensive product portfolio includes components for diesel fuel systems, engine management, gasoline fuel systems, vehicle electronics, and maintenance solutions. Delphi Technologies takes pride in its state-of-the-art manufacturing facility as well as OE-level diagnostic and test equipment that produces OE-quality aftermarket components to make vehicles and trucks run cleaner, drive better, and last further.
