RAYBESTOS 782850 Part Description
Manufacturer
Product Description
Raybestos Specialty - Truck Brake Rotor
Features & Benefits
- OE Fit, Form, and Function
- Our vehicle-specific design matches OE fit, form and function, providing ultimate strength and performance
- Cooling Vanes
- We dedicate time to match the cooling vanes on our Specialty rotors to OE designs, ensuring: Optimal cooling Reduced fade Less noise Increased pad life
- Coating
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0® rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0(R) rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- SAE Standard for Tensile Strength
- Our rotors follow SAE standards for tensile strength, hardness, and iron grade, providing structural integrity and maximum service life
- Turned Finish
- A turned finish provides an excellent surface for the pads to engage with to ensure a smooth and effective stop right out of the box
Raybestos Specialty - Truck Brake Rotor
RAYBESTOS 782850 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.835 IN |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 0.787 IN |
| Inside Diameter | 9.291 IN |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 5 IN |
| Mounting Bolt Hole Diameter | 0.661 IN |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.866 IN |
| Outside Diameter | 13.78 IN |
| Overall Height | 1.618 IN |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Construction | Full Cast |
| Grade Type | Regular |
| Harmonize Code | 8708.30.5030 |
| Salability Restrictions | No |
| UNSPSC Code | 25171715 |
| Misc. Holes | 5 |
| Center Hole Diameter | 72 MM |
| Discard Thickness | 20 MM |
| Inside Diameter | 236 MM |
| Mounting Bolt Hole Circle Diameter | 127 MM |
| Mounting Bolt Hole Diameter | 16.8 MM |
| Nominal Thickness | 22 MM |
| Outside Diameter | 350 MM |
| Overall Height | 41.1 MM |
Additional Information
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
RAYBESTOS 782850 Cross References
| Brand | Part Number |
|---|---|
| Advance Auto Parts | YH737159HC |
| Centric Parts | 120.58025, 121.58025 |
| Chrysler | 68341651AA, 68463428AA |
| DuraGo | BR901968, BR901968-01 |
| Dynamic Friction Company | 604-42045 |
| Jeep | 68341651AA |
| WORLDPAC | 1407-737159, 1427-737160 |
| Winhere | 6622928 |
RAYBESTOS 782850 Fits Vehicles
- Jeep Grand Cherokee (2022-2024)
- Jeep Grand Cherokee L (2021-2024)
