LINCOLN ELECTRIC part description

Easy-Mig® 140 Wire Feeder Welder - 120-Volt Input Power, for Gasless Flux-Cored Welding or Gas Shielded Mig Welding



Product Specifications:
Machines Processes: MIG (GMAW)
Flux-Cored Self-Shielded (FCAW-S)
Input Voltage: 110/115/120
Input Current: 20A
Input Hertz: 60
Input Phase: 1
Input Power: 120/1/60
Mode Icon: CV
Output Range: 30-140A
Polarity: DC
Machines Maximum Weldable Thickness (in.): 5/16"
Machines Minimum Weldable Thickness (Ga.): 24 Ga.
Welding Gun Cable Assembly Length (ft.): 10 ft.
Work Cable Length (ft.): 10 ft.
Number Of Driven Rolls: 1 Roll
Feeder Type: Portable
Wire Feeders Processes: MIG
Flux Cored
Input AC Voltage: 120V
Maximum Wire Thickness: 0.035
Minimum Wire Thickness: 0.025
Wire Feed Duty Cycle: 20%

Features & Benefits

  • Forgiving arc makes dialing in your application easy
  • Smooth arc starts with minimal spatter
  • Wide 30-140 amp welding output range
  • Precision full adjustment drive system reduces chance of wire tangling and crushing
  • Large industrial closed-design drive motor for improved torque and trouble free performance
  • Whether you have a home project, farm repairs or basic autobody welding to complete, the Easy MIG® 140 should be at the top of your shopping list! Requiring common 120 volt input power, the Easy MIG® 140 can be used almost anywhere. With simple two knob tapped control, the machine is easy to set up for gas-less flux-cored welding for deep penetration on thicker steel or gas-shielded MIG welding on thin gauge steel, stainless or aluminum. Compare the precise drive, rugged construction and full list of standard accessories. . . Lincoln Easy MIG® 140 is an excellent choice!
  • Wide amperage range (30–140A) supports light and mid-duty projects

Features & Benefits

  • Forgiving arc response makes it easier to fine-tune for your task
  • Smooth starts and low spatter for cleaner, consistent welds
  • Wide amperage range (30–140A) supports light and mid-duty projects
  • Full-adjustment wire feed system prevents tangling and crushing
  • Closed-design drive motor improves torque and reduces maintenance
  • Operates on common 120V power—ideal for home, farm, or garage use

Lincoln Electric EASY MIG® 140

Tackling farm repairs or autobody jobs with a 120V welder shouldn’t mean compromising on power or performance—that’s where the Lincoln Electric EASY MIG® 140 steps in. This portable unit offers a forgiving arc and smooth start-up, minimizing spatter and giving users better control over every weld. Whether you’re in a shop, garage, or field, the Lincoln Electric K2471-1 delivers professional-level results with simple setup.
