(888) 312-8812 Login SignupRAYBESTOS 980566 Raybestos Specialty - Truck Brake Rotor
$177.25
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
RAYBESTOS 980566 Part Description
Manufacturer
Product Description
Raybestos Specialty - Truck Brake Rotor
Application Summary
2015-2009 Honda Pilot Front, 2013-2007 Acura MDX Front, 2020-2014 Acura RLX Front, 2013-2010 Acura ZDX Front
Features & Benefits
- OE Fit, Form, and Function
- Our vehicle-specific design matches OE fit, form and function, providing ultimate strength and performance
- Cooling Vanes
- We dedicate time to match the cooling vanes on our Specialty rotors to OE designs, ensuring: Optimal cooling Reduced fade Less noise Increased pad life
- We dedicate time to match the cooling vanes on our Specialty rotors to OE designs, ensuring:Optimal coolingReduced fadeLess noiseIncreased pad life
- Coating
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0® rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0(R) rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- SAE Standard for Tensile Strength
- Our rotors follow SAE standards for tensile strength, hardness, and iron grade, providing structural integrity and maximum service life
- Turned Finish
- A turned finish provides an excellent surface for the pads to engage with to ensure a smooth and effective stop right out of the box
RAYBESTOS 980566 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.76 IN |
| Center Hole Diameter | 70.1 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 1.024 IN |
| Discard Thickness | 26 MM |
| Harmonize Code | 8708.30.5030 |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 4.72 IN |
| Mounting Bolt Hole Circle Diameter | 119.9 MM |
| Mounting Bolt Hole Diameter | 0.566 IN |
| Mounting Bolt Hole Diameter | 14.4 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.102 IN |
| Nominal Thickness | 28 MM |
| Outside Diameter | 12.984 IN |
| Outside Diameter | 329.8 MM |
| Overall Height | 1.858 IN |
| Overall Height | 47.2 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352604304 |
RAYBESTOS 980566 Cross References
| Brand | Part Number |
|---|---|
| BRC221RM, 829352604304 | |
| ADVANCE AUTO PARTS | YH200523, YH200523C, YH200523P |
| AUTOPARTSOURCE | 471350, 471600, 571350 |
| AUTOXTRA | AX900530 |
| AUTOZONE | 44605, 44605DG |
| AutoZone | 44605DL |
| Autoxtra | AX900530P |
| BENDIX | PRT5783 |
| BOSCH | 26011445 |
| BRAKEBEST | 26011445, 980566, 980566FZN, 980566R |
| BrakeBest | 980566RGS |
| Brembo | 09.E236.11 |
| CENTRIC | 120.40071, 120.40071CRY, 121.40071, 126.40071CSL, 126.40071CSR, 126.40071SL, 126.40071SR, 127.40071CL, 127.40071CR, 127.40071L, 127.40071R, 128.40071CL, 128.40071CR, 128.40071L, 128.40071R, 227.40071L, 227.40071R, 320.40071, 321.40071 |
| Centric Parts | 120.40071, 120.40071CRY, 121.40071, 126.40071CSL, 126.40071CSR, 126.40071SL, 126.40071SR, 127.40071CL, 127.40071CR, 127.40071L, 127.40071R, 128.40071CL, 128.40071CR, 128.40071L, 128.40071R, 227.40071L, 227.40071R, 320.40071, 321.40071 |
| DURA CORP | BR31468, BR900530, BR90053002 |
| DuraGo | 900530, BR900530, BR90053002, BR900530-02 |
| Dynamic Friction Company | 604-59053 |
| HONDA | 45251STXA00, 45251STXA01, 45251STXH01, 45251TY3A00 |
| MAGMA PRODUCTS | PSR265101 |
| MONROE BRAKES | BD180044 |
| NEOTEK | 106237GF |
| NEWTEK AUTOMOTIVE | 31468 |
| Newtek Automotive USA | 31468 |
| Omnicraft | QBRR110 |
| POWERSTOP | JBR1171EVC |
| PROMAX | 14-31468, 20-31468 |
| PRONTO | BR900530 |
| Qualis | 44605 |
| TopNotch | TN980566GEO |
| UAP | 2031468, 31468 |
| WABCO | PS180044 |
| WABCO - Archived | PS180044 |
| WAGNER | BD180044E, BD180044 |
| WAGNER BRAKE | BD180044, BD180044E |
| WINHERE | 6620989 |
| WORLDPAC | 1407-83037, 1427-731742 |
RAYBESTOS 980566 Fits Vehicles
- Acura MDX (2007-2013)
- Acura RLX (2014-2020)
- Acura ZDX (2010-2013)
- Honda Pilot (2009-2015)
