RAYBESTOS 5501 Part Description
Manufacturer
Product Description
Raybestos Specialty - Street Performance Brake Rotor
Application Summary
1982-1963 Chevrolet Corvette Rear, 1969-1968 Chevrolet Camaro Front, 1969-1968 Chevrolet Camaro Rear
Features & Benefits
- Application Specific Enhanced Iron
- Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Cooling Vanes
- The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
- Application Specific Coating
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
- Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
- Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
- Turned Finish
- Turned finish minimizes noise and improves responsiveness for smoother stops.
- S-Groove Slot
- Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
- Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.
RAYBESTOS 5501 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.814 IN |
| Center Hole Diameter | 71.5 MM |
| Conventional Or Drum-In-Hat Type Rotor | Drum-In-Hat |
| Discard Thickness | 1.215 IN |
| Discard Thickness | 30.85 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 4.75 IN |
| Mounting Bolt Hole Circle Diameter | 120.65 MM |
| Mounting Bolt Hole Diameter | 0.457 IN |
| Mounting Bolt Hole Diameter | 11.6 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.245 IN |
| Nominal Thickness | 31.6 MM |
| Outside Diameter | 11.75 IN |
| Outside Diameter | 298.45 MM |
| Overall Height | 3.09 IN |
| Overall Height | 78.5 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00030999078797 |
RAYBESTOS 5501 Cross References
| Brand | Part Number |
|---|---|
| ACDELCO | 177-639 |
| ADVANCE AUTO PARTS | 141213, YH141213 |
| AMERICAN REMANUFACTURED | 789-36007, 89-36007 |
| AUTOSPECIALTY | AR8207, AR8207E |
| AUTOXTRA | 60401, AX5541 |
| AUTOZONE | 5541 |
| BENDIX | 141213 |
| BOSCH | 25010637 |
| BRAKE HEADQUARTERS | BR55410 |
| BRAKE PRO | 4615501 |
| BRAKEBEST | 25010637, 5501, 5501R, 5501RGS, BD60401 |
| CALIFORNIA DRUM & ROTOR | 60401, 60406 |
| CENTRIC | 120.62007, 121.62007, 125.62007, 125.62007CRY, 126.62007CSL, 126.62007CSR, 126.62007SL, 126.62007SR, 127.62007CL, 127.62007CR, 127.62007L, 127.62007R, 128.62007L, 128.62007R, 227.62007L, 227.62007R, 320.62007F |
| CENTURY | 5007 |
| Casting Numbers | 325674, 635007 |
| Centric Parts | 120.62007, 121.62007, 125.62007, 125.62007CRY, 126.62007CSL, 126.62007CSR, 126.62007SL, 126.62007SR, 127.62007CL, 127.62007CR, 127.62007L, 127.62007R, 128.62007L, 128.62007R, 227.62007L, 227.62007R, 320.62007F |
| DAYTON WALTHER | 69110585 |
| DURA CORP | BR5541 |
| DuraGo | BR5541 |
| Dynamic Friction Company | 604-47008 |
| EIS BRAKES | D5007 |
| EUROROTOR | 5541 |
| GM | 12309946, 3865905, 3996663 |
| GREN | 661702 |
| General Motors | 12309946, 3865905, 3996663 |
| HOLLANDER | 1014 |
| KELSEY HAYES | 14557, 86834 |
| MAGMA PRODUCTS | PSR223002 |
| MCI | 5087 |
| MIDAS | BR1208, BR1274 |
| MIGHTY DISTRIBUTING SYSTEM | 5541 |
| MONROE BRAKES | BD60401 |
| NEWTEK AUTOMOTIVE | 5541 |
| Newtek Automotive USA | 5541 |
| PEP BOYS | 5541G |
| PRONTO | BR5541 |
| QUALIS | 5541 |
| QUALITEE INTERNATIONAL | 64-93-810 |
| QUALITY BRAND | 5541 |
| ROADMATES | 526059 |
| ROCKHILL | 5541 |
| STANDARD ROTORS AND DRUMS | 5541 |
| TEKNOMAC | 11270 |
| THE UNIVERSAL GROUP | 101410 |
| TRUSTAR | 493810, R93810 |
| UAP | 5541 |
| Universal | 101410 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X50043 |
| WAGNER | BD60401 |
| WAGNER BRAKE | BD60401, BD60406 |
| WINHERE | YH2283 |
RAYBESTOS 5501 Fits Vehicles
- Chevrolet Camaro (1968-1969)
- Chevrolet Corvette (1963-1982)
