HELLA part description

Product Description

Features & Benefits

  • HELLA VALUEFIT Series Offers Affordable Lighting Applications and Powerful LED Performance HELLA VALUEFIT lighting series is a comprehensive line of affordable lighting for a multitude of vehicle applications.
  • HELLA VALUEFIT is designed to meet all of the critical quality requirements for aftermarket lighting, yet is still available without the higher cost of classic premium products. The VALUEFIT line includes a wide range of worklights.

Product Attributes

Operating Temperature To [c°] +60
Voltage [V] 24
Protection Type (IP Code) IP67
Test Mark ECE R10
Number of LEDs 24
Weight [g] 509
Operating Temperature From [°c] -40
Power Consumption [w] 24
Quantity 1
Outer Diameter 1 [mm] 142
Assy./disassy. By Qualified Personnel Required! .
Height [mm] 165
Diffusing Lens Material PC (Polycarbonate)
Colour Yellow
Light Function With flashing warning signal
Lamp Type LED
Supplementary Article/Info 2 with overvoltage protection
Mounting Type Flexible pipe sockets
Lens Colour Yellow
Reverse polarity protection Yes
Housing Material Aluminium
Light Design LED

Additional Information

Harmonized Tariff Code (HTS) 8512204040
Warranty Time UOM MO
Warranty Time 12
Country of Origin (Primary) CN
UPC 04082300840971

Headquartered in Northville, Michigan, HELLA USA® is a wholly-owned subsidiary of HELLA GmbH & Co. KGaA. It was established in 1998 with a primary focus on providing corporate-based services, including sales, purchasing, marketing support, and information management. Since it is a globally focused, top-tier supplier, HELLA USA delivers premium, groundbreaking products with a business mindset. The brand's extensive manufacturing experience, combined with cutting-edge technology and state-of-the-art facility, makes it possible for Hella U.S.A. to deliver top-notch powertrain components, safety solutions, premium-quality comfort features, and styling products. Through its Automotive Segment, Hella provides the automotive and trucking industry with lighting and electronic componentry and other products like intelligent battery sensors, adaptive lighting systems, and radar-based driver-assistance systems.
