TrakMotive GM-8046 - CV Axle Shaft
- Part Number
- GM-8046
- Manufacturer
- TRAKMOTIVE
- Description
-
CV Axle Shaft
details
$10749
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
TRAKMOTIVE part description
Product Description
CV Axle Shaft
Product Attributes
| ABS Ring Tooth Count | 0 |
| ABS Ring Type | N/A |
| Abs Tone Ring Included | No |
| Axle Bolt Hex Size (mm) | N/A |
| Axle Bolt Length (mm) | N/A |
| Axle Bolt Thread Size | N/A |
| Axle Nut Head Type | Hex |
| Axle Nut Height (in) | .86 |
| Axle Nut Height (mm) | 22 |
| Axle Nut Hex Size (in) | 1.29 |
| Axle Nut Hex Size (mm) | 33 |
| Axle Nut Included | Yes |
| Axle Nut Length (in) | 1.5 |
| Axle Nut Length (mm) | 38 |
| Axle Nut Locking Type | Self-Lock |
| Axle Nut Thread Size | M27x2 |
| Boot Material | Neoprene |
| Inboard Bolt Head Size (in) | N/A |
| Inboard Bolt Head Size (mm) | N/A |
| Inboard Bolt Head Type | N/A |
| Inboard Bolt Length (in) | N/A |
| Inboard Bolt Length (mm) | N/A |
| Inboard Bolt Thread Size | N/A |
| Inboard Joint Type | Female |
| Inboard Shaft Connection Style | Female |
| New Or Remanufactured | New |
| Number of Bolt Holes | 0 |
| Number Of Inboard Joint Bolt Holes | 0 |
| Number Of Inboard Shaft Bolts | 0 |
| Number Of Inboard Splines | 35 |
| Number Of Outboard Joint Bolt Holes | 0 |
| Number Of Outboard Shaft Bolts | 0 |
| Number Of Outboard Splines | 33 |
| Outboard Bolt Head Size (in) | N/A |
| Outboard Bolt Head Size (mm) | N/A |
| Outboard Bolt Head Type | N/A |
| Outboard Bolt Length (in) | N/A |
| Outboard Bolt Length (mm) | N/A |
| Outboard Joint Bolt Thread Size | N/A |
| Outboard Joint Type | Conventional |
| Outboard Shaft Connection Style | Conventional |
| Overall Compressed Length (in) | 22.13 |
| Overall Compressed Length (mm) | 562 |
| Axle Nut Socket Size | 33 |
| Grade Type | Premium |
| Inboard Joint Boot Material | Neoprene |
| Outboard Joint Boot Material | Neoprene |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708508500 |
| UPC | 00844084030467 |
Part Interchanges
- ARC 80-2526
- ARC 80-2534
- ARC 80-2571
- EMPI 80-1804
- Car Components Technologies (CCT) 9573
- Mevotech CV5369
- Carquest 410371
- Carquest 800371
- USA Industries 708576
- USA Industries AX-8576
- American Remanufactured 40-16223
- Diversified Shafts Solutions 1349N
- Drive Tech America GM-6223
- Fenwick CV3895
- CARDONE Reman 60-1249
- CARDONE Reman 66-1249
- IMC 40720133
- OEM Part Number 26035206
- OEM Part Number 26047918
- ODM GC-8-8635
- TrakMotive GM-8046
- ProTech GM10507
- 410371
- NCV10233
- 70273
- 179046
Fits Vehicles
- Pontiac Trans Sport (1997-1998)
- Pontiac Grand Prix (1997-1999)
- Oldsmobile Silhouette (1997-1998)
- Chevrolet Venture (1997-1998)
- Buick Riviera (1995-1996)
- Buick Regal (1997)
- Buick Century (1997-1999)
