Main Filter MF0424234 - Aftermarket Replacement Hydraulic Filter with 25 Micron Rating, Cellulose, Outside-In Flow
- Part Number
- MF0424234
- Manufacturer
- MAIN FILTER
- Description
-
Aftermarket Replacement Hydraulic Filter with 25 Micron Rating, Cellulose, Outside-In Flow
details
$2199
MSRP: $23.34
Save: $1.35
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
MAIN FILTER part description
Technical Specifications
| Outside Diameter Top | 2.047 |
| Inide Diameter Top | 0.965 |
| Outside Diameter Bottom | 2.047 |
| BPVS Setting PSI | 25 |
| Collapse Pressure | 44 |
| Operating Temp Min F | -13 |
| Operating Temp Max F | 248 |
| Capacity gr | 2.4304 |
| Filter Area sq in | 61 |
| Flow Direction | Outside-In |
| Gasket Material | Viton |
| Fluid Type | HH / HL / HM / HV |
| Beta Ratio 1 | 2/25 |
| Micron 1 | 25 |
Features & Benefits
- Interchange/replacement for OEM FILTER-X p/n XH02853
- Compatible with OEM filter in fit, form and function
- All of our elements are manufactured following ISO specifications.
- Buy hydraulic filters direct from the manufacturer
- Built using Quality Components with strict quality control.
- Main Filter MF0424234 replaces OEM XH02853 by FILTER-X and is compatible in fit, form and function.
- All of our elements are manufactured according to ISO specifications, including: ISO 16889, Clean DP (low and high visc) - ISO 3968, Fluid compatibility - ISO 2943, Flow fatigue resistance - ISO 3724, Dirt capacity - ISO 16889, Collapse pressure - ISO 2941
- All items marked "Replacement" or "Interchange" are not affiliated with the original manufacture where names and part numbers are for cross reference only. All trademarks are trademarks of their respective owners. Reference is made to the OEM solely to identify the compatibility of Main Filter Inc filter with the OEM filter.
- Images may be a general representations of products
- All of our elements are manufactured according to ISO specifications, including: ISO 16889, Clean DP (low and high visc) - ISO 3968, Fluid compatibility - ISO 2943, Flow fatigue resistance - ISO 3724, Dirt capacity - ISO 16889, Collapse pressure - ISO 2941
- Built using Quality Components with strict quality control.
- All items marked "Replacement" or "Interchange" are not affiliated with the original manufacture where names and part numbers are for cross reference only. All trademarks are trademarks of their respective owners. Reference is made to the OEM solely to identify the compatibility of Main Filter Inc filter with the OEM filter.
Features & Benefits
- Interchange/replacement for OEM FILTER-X p/n XH02853
- Compatible with OEM filter in fit, form and function
- All of our elements are manufactured following ISO specifications.
- Buy hydraulic filters direct from the manufacturer
- Built using Quality Components with strict quality control.
- Main Filter MF0424234 replaces OEM XH02853 by FILTER-X and is compatible in fit, form and function.
- All of our elements are manufactured according to ISO specifications, including: ISO 16889, Clean DP (low and high visc) - ISO 3968, Fluid compatibility - ISO 2943, Flow fatigue resistance - ISO 3724, Dirt capacity - ISO 16889, Collapse pressure - ISO 2941
- All items marked "Replacement" or "Interchange" are not affiliated with the original manufacture where names and part numbers are for cross reference only. All trademarks are trademarks of their respective owners. Reference is made to the OEM solely to identify the compatibility of Main Filter Inc filter with the OEM filter.
- Images may be a general representations of products
Product Attributes
| Height (in.) | 2.95 |
| Product Media | Cellulose |
| Bypass | Yes |
| Micron Rating | 25 |
| Handle | Yes |
| Wrap | No |
| Outside Diameter (Top) | 2.05 in. |
| Outside Diameter (Bottom) | 2.05 in. |
| Inside Diameter (Top) | 0.97 in. |
| Collapse Pressure | 44 |
| Maximum Operating Temperature | 248 Deg Fahrenheit |
| BPVS Setting (PSI) | 24.7 |
| Minimum Operating Temperature | -13 Deg Fahrenheit |
| Dust Holding Capacity | 2.43 grams |
| Gasket Material | Viton |
| Fluid Type | HH / HL / HM / HV |
| Flow Direction | Outside-In |
| Filter Area (sq. in.) | 61 |
| Beta Ratio 1 | 2/25 |
MAIN FILTER MF0424234 Cross Reference
We have 1 alternatives for the MF0424234 by MAIN FILTER:
