Name: Main Filter MF0796494 Aftermarket Replacement Hydraulic Filter with 3 Micron Rating, Glass, Outside-In Flow
SKU: mf0796494
Price: 55.49 USD
Availability: InStock

MAIN FILTER part description

Technical Specifications

Outside Diameter Top	2.028
Outside Diameter Bottom	2.028
Inside Diameter Bottom	0.874
BPVS Setting PSI	44
Collapse Pressure	435
Operating Temp Min F	-13
Operating Temp Max F	248
Capacity gr	11.64205
Filter Area sq in	157
Flow Direction	Outside-In
Gasket Material	Viton
Fluid Type	HH / HL / HM / HV
Beta Ratio 1	200/3
Beta Ratio 2	1000/4.5
Micron 1	3

Features & Benefits

Interchange/replacement for OEM SCHROEDER p/n SBF0110RZ3V
Compatible with OEM filter in fit, form and function
All of our elements are manufactured following ISO specifications.
Buy hydraulic filters direct from the manufacturer
Built using Quality Components with strict quality control.
Main Filter MF0796494 replaces OEM SBF0110RZ3V by SCHROEDER and is compatible in fit, form and function.
All of our elements are manufactured according to ISO specifications, including: ISO 16889, Clean DP (low and high visc) - ISO 3968, Fluid compatibility - ISO 2943, Flow fatigue resistance - ISO 3724, Dirt capacity - ISO 16889, Collapse pressure - ISO 2941
All items marked "Replacement" or "Interchange" are not affiliated with the original manufacture where names and part numbers are for cross reference only. All trademarks are trademarks of their respective owners. Reference is made to the OEM solely to identify the compatibility of Main Filter Inc filter with the OEM filter.
Images may be a general representations of products
All items marked "Replacement" or "Interchange" are not affiliated with the original manufacture where names and part numbers are for cross reference only. All trademarks are trademarks of their respective owners. Reference is made to the OEM solely to identify the compatibility of Main Filter Inc filter with the OEM filter.

Features & Benefits

Interchange/replacement for OEM SCHROEDER p/n SBF0110RZ3V
Compatible with OEM filter in fit, form and function
All of our elements are manufactured following ISO specifications.
Buy hydraulic filters direct from the manufacturer
Built using Quality Components with strict quality control.
Main Filter MF0796494 replaces OEM SBF0110RZ3V by SCHROEDER and is compatible in fit, form and function.
All of our elements are manufactured according to ISO specifications, including: ISO 16889, Clean DP (low and high visc) - ISO 3968, Fluid compatibility - ISO 2943, Flow fatigue resistance - ISO 3724, Dirt capacity - ISO 16889, Collapse pressure - ISO 2941
All items marked "Replacement" or "Interchange" are not affiliated with the original manufacture where names and part numbers are for cross reference only. All trademarks are trademarks of their respective owners. Reference is made to the OEM solely to identify the compatibility of Main Filter Inc filter with the OEM filter.
Images may be a general representations of products

Product Attributes

Handle	Yes
Micron Rating	3
Wrap	No
Minimum Operating Temperature	-13 Deg Fahrenheit
Maximum Operating Temperature	248 Deg Fahrenheit
Flow Direction	Outside-In
Filter Area (sq. in.)	157
Dust Holding Capacity	11.64 grams
Bypass	Yes
Product Media	Glass
Outside Diameter (Top)	2.03 in.
BPVS Setting (PSI)	43.5
Gasket Material	Viton
Beta Ratio 2	1000/4.5
Height (in.)	6.71
Collapse Pressure	290
Beta Ratio 1	200/3
Fluid Type	HH / HL / HM / HV

Part Interchanges

Schroeder SBF0110RZ3V

MAIN FILTER MF0796494 Cross Reference

We have 1 alternatives for the MF0796494 by MAIN FILTER:

SCHROEDER SBF0110RZ3V
