MAIN FILTER part description

Technical Specifications

Outside Diameter Top 3.071
Inide Diameter Top 1.701
Outside Diameter Bottom 3.071
Collapse Pressure 305
Operating Temp Min F -13
Operating Temp Max F 248
Capacity gr 75.332
Filter Area sq in 1018
Flow Direction Outside-In
Gasket Material Viton
Fluid Type HH / HL / HM / HV
Beta Ratio 1 200/3
Beta Ratio 2 1000/4.5
Micron 1 3

Features & Benefits

  • Interchange/replacement for OEM BALDWIN p/n H9083
  • Compatible with OEM filter in fit, form and function
  • All of our elements are manufactured following ISO specifications.
  • Buy hydraulic filters direct from the manufacturer
  • Built using Quality Components with strict quality control.
  • Main Filter MF0277893 replaces OEM H9083 by BALDWIN and is compatible in fit, form and function.
  • All of our elements are manufactured according to ISO specifications, including: ISO 16889, Clean DP (low and high visc) - ISO 3968, Fluid compatibility - ISO 2943, Flow fatigue resistance - ISO 3724, Dirt capacity - ISO 16889, Collapse pressure - ISO 2941
  • All items marked "Replacement" or "Interchange" are not affiliated with the original manufacture where names and part numbers are for cross reference only. All trademarks are trademarks of their respective owners. Reference is made to the OEM solely to identify the compatibility of Main Filter Inc filter with the OEM filter.
  • Images may be a general representations of products
  • Interchange/replacement for OEM BALDWIN p/n H9083
  • Built using Quality Components with strict quality control.
  • Images may be a general representations of products
  • Interchange/replacement for OEM BALDWIN p/n H9083
  • Built using Quality Components with strict quality control.
  • Images may be a general representations of products

Features & Benefits

  • Interchange/replacement for OEM BALDWIN p/n H9083
  • Compatible with OEM filter in fit, form and function
  • All of our elements are manufactured following ISO specifications.
  • Buy hydraulic filters direct from the manufacturer
  • Built using Quality Components with strict quality control.
  • Main Filter MF0277893 replaces OEM H9083 by BALDWIN and is compatible in fit, form and function.
  • All of our elements are manufactured according to ISO specifications, including: ISO 16889, Clean DP (low and high visc) - ISO 3968, Fluid compatibility - ISO 2943, Flow fatigue resistance - ISO 3724, Dirt capacity - ISO 16889, Collapse pressure - ISO 2941
  • All items marked "Replacement" or "Interchange" are not affiliated with the original manufacture where names and part numbers are for cross reference only. All trademarks are trademarks of their respective owners. Reference is made to the OEM solely to identify the compatibility of Main Filter Inc filter with the OEM filter.
  • Images may be a general representations of products

Product Attributes

Bypass No
Beta Ratio 1 200/3
Beta Ratio 2 1000/4.5
Collapse Pressure 305
Dust Holding Capacity 75.33 grams
Maximum Operating Temperature 248 Deg Fahrenheit
Fluid Type HH / HL / HM / HV
Wrap No
Inside Diameter (Top) 1.72 in.
Outside Diameter (Bottom) 3.09 in.
Filter Area (sq. in.) 1018
Minimum Operating Temperature -13 Deg Fahrenheit
Handle No
Gasket Material Viton
Product Media Glass
Outside Diameter (Top) 3.09 in.
Flow Direction Outside-In
Height (in.) 16.85
Micron Rating 3

Part Interchanges

MAIN FILTER MF0277893 Cross Reference

We have 1 alternatives for the MF0277893 by MAIN FILTER:
