MAIN FILTER part description

Technical Specifications

Outside Diameter Top 1.752
Inide Diameter Top 0.87
Outside Diameter Bottom 1.752
Collapse Pressure 3045
Operating Temp Min F -13
Operating Temp Max F 248
Capacity gr 1.50319
Filter Area sq in 58
Flow Direction Outside-In
Gasket Material Viton
Fluid Type HH / HL / HM / HV
Beta Ratio 1 200/3
Micron 1 3

Features & Benefits

  • Interchange/replacement for OEM SEPARATION TECHNOLOGIES p/n H060D03V
  • Compatible with OEM filter in fit, form and function
  • All of our elements are manufactured following ISO specifications.
  • Buy hydraulic filters direct from the manufacturer
  • Built using Quality Components with strict quality control.
  • Main Filter MF0343260 replaces OEM H060D03V by SEPARATION TECHNOLOGIES and is compatible in fit, form and function.
  • All of our elements are manufactured according to ISO specifications, including: ISO 16889, Clean DP (low and high visc) - ISO 3968, Fluid compatibility - ISO 2943, Flow fatigue resistance - ISO 3724, Dirt capacity - ISO 16889, Collapse pressure - ISO 2941
  • All items marked "Replacement" or "Interchange" are not affiliated with the original manufacture where names and part numbers are for cross reference only. All trademarks are trademarks of their respective owners. Reference is made to the OEM solely to identify the compatibility of Main Filter Inc filter with the OEM filter.
  • Images may be a general representations of products
  • Interchange/replacement for OEM SEPARATION TECHNOLOGIES p/n H060D03V
  • Built using Quality Components with strict quality control.
  • Images may be a general representations of products
  • Buy hydraulic filters direct from the manufacturer
  • Images may be a general representations of products
  • Images may be a general representations of products

Features & Benefits

  • Interchange/replacement for OEM SEPARATION TECHNOLOGIES p/n H060D03V
  • Compatible with OEM filter in fit, form and function
  • All of our elements are manufactured following ISO specifications.
  • Buy hydraulic filters direct from the manufacturer
  • Built using Quality Components with strict quality control.
  • Main Filter MF0343260 replaces OEM H060D03V by SEPARATION TECHNOLOGIES and is compatible in fit, form and function.
  • All of our elements are manufactured according to ISO specifications, including: ISO 16889, Clean DP (low and high visc) - ISO 3968, Fluid compatibility - ISO 2943, Flow fatigue resistance - ISO 3724, Dirt capacity - ISO 16889, Collapse pressure - ISO 2941
  • All items marked "Replacement" or "Interchange" are not affiliated with the original manufacture where names and part numbers are for cross reference only. All trademarks are trademarks of their respective owners. Reference is made to the OEM solely to identify the compatibility of Main Filter Inc filter with the OEM filter.
  • Images may be a general representations of products

Product Attributes

Collapse Pressure 3045
Filter Area (sq. in.) 58
Minimum Operating Temperature -13 Deg Fahrenheit
Maximum Operating Temperature 248 Deg Fahrenheit
Flow Direction Outside-In
Bypass No
Outside Diameter (Bottom) 1.75 in.
Gasket Material Viton
Beta Ratio 1 200/3
Handle No
Dust Holding Capacity 1.5 grams
Fluid Type HH / HL / HM / HV
Micron Rating 3
Inside Diameter (Top) 0.87 in.
Height (in.) 3.58
Outside Diameter (Top) 1.75 in.
Product Media Stainless Steel Fiber
Wrap No

Part Interchanges

MAIN FILTER MF0343260 Cross Reference

We have 1 alternatives for the MF0343260 by MAIN FILTER:
