E3 SPARK PLUGS part description

Premium Automotive Spark Plug; Resistor; 5/8 in. Hex Size; 0.866 in. Thread Reach; 16mm Thread Diameter; Taper Seat; DiamondFIRE Tip w/Fixed Gap;

Product Description

Premium Automotive Spark Plug

Features & Benefits

  • Patented DiamondFIRE Ground Electrode
  • Edge-To-Edge Ground Electrode Out Performs Other Plug Designs
  • E3 Equipped Engines Can Minimize Venting Of Unburned Fuel
  • Burn Fuel More Efficiently By Burning Fuel More Completely
  • Provide A Like-New Performance For The Life Of The Plug
  • The Most Environmentally-Friendly Plug Available

Product Attributes

WARNING CA Proposition 65 Yes
Application Specific or Non-Application Application Specific
Brand Name E3 Spark Plugs
Bullet Efficiency - E3 "diamond shaped" side wire electrode projects the combustion spark in a way that more quickly ignites the air/fuel mixture, thereby creating a significantly faster and longer flame kernel, more fuel is put to work with less waste; creating improved fuel economy-results will vary
Center Electrode Core Material Copper
Center Electrode Tip Material Nickel
Electrode Core Copper
Electrode Tip Nickel
Features & Benefits E3 Spark Plugs are the product of years of fundamental research in the combustion field. The unique patented ground electrode configuration increases the amount of combustion pressure created during each power stroke of the engine, which results in a marked increase in power output, fuel economy, and reduced emissions in all gasoline engines. E3's DiamondFire edge to edge ground electrode provides maximum performance with increased efficiency and a faster more complete burn.
Gap Pre-gapped at the factory to meet O.E. requirements; Gap cannot be adjusted
Ground Electrode Tip Material Nickel
Hex Size 5/8 IN
Insulator Height 2.507 IN
Insulator Height 63.67 MM
Part Type Name Automotive Spark Plug
Pre-Gap Size .040 IN
Pre-Gap Size 1.016 MM
Reach 1.0 IN
Reach 25.4 MM
Resistor Resistor
Seat Style Tapered
Spark Plug Approximate Resistor Value 3500-7000 82
Thread Size 16 MM

Additional Information

Country of Origin (Primary) CN
Harmonized Tariff Code (Schedule B) 8511100000
Harmonized Tariff Code (HTS) 8511100000
NAFTA Preference Criterion Code B
Warranty Special E3 PowerSport spark plugs properly installed in non-commercial equipment; are wa
Warranty Special UOM TX
UPC 00894489000701

Part Interchanges

Fits Vehicles

  • Ford F-53 Motorhome Chassis (2004, 2006-2008)
  • Ford Explorer Sport Trac (2007-2008)
  • Mercury Mountaineer (2006-2008)
  • Ford Explorer (2006-2008)
  • Lincoln Mark LT (2006-2008)
  • Ford Mustang (2005-2008)
  • Ford F-250 Super Duty (2005-2008)
  • Ford F-350 Super Duty (2005-2008)
  • Ford F-450 Super Duty (2005-2008)
  • Ford F-550 Super Duty (2005-2008)
  • Lincoln Navigator (2005-2008)
  • Ford Expedition (2005-2008)
  • Ford F-150 (2004-2008)
