Eaton 3270-1010-0100 - 3270 Series Airbrake Hose and Tubing - .625" OD, .44" ID, 1 Ply Braid, Nylon
$330
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
EATON part description
Product Attributes
| Color | Black |
| Inside Diameter | .44 in. |
| Outside Diameter | .625 in. |
| Abrasion resistance | Premium |
| Application | Truck air brake systems, trailer air brake systems, auxiliary air systems, formed tubes, formed and straight air brake harness assemblies. |
| Bend radius - min | 2.5 in. |
| Burst Pressure | 900 PSI |
| Certifications | SAE J844,SAE J2494-2,SAE J1131 |
| Compliances | DOT FMVSS 106 |
| Conductivity | Non-Conductive |
| Construction | 1 Ply Braid |
| Cover Material | Polyester |
| Dash Size | -10 |
| Impulse cycle life | 125000 Cycles |
| Lay line style | Ink Jet |
| Reinforcement Material | Synthetic fiber |
| Tube Material | Nylon |
| Tube Wall Thickness | .09 in. |
| Working Pressure | 225 PSI |
| Working temperature - max | 200 F |
| Working temperature - min | -40 F |
