HELLA 002952861 Part Description
Manufacturer
Product Description
HELLA Horn 002952861
Features & Benefits
- Black diaphragm and galvanized metal
- Enhances road safety by emitting a 335 Hz tone, providing clear and audible alerts in all conditions.
- Delivers maximum awareness with a volume output ranging from 108 dB(A) to 118 dB(A), ensuring audibility.
- Ensures long-term reliability with robust construction engineered to withstand vibration and harsh conditions.
- Facilitates fast identification and installation with concise short codes, streamlining maintenance and replacement.
- Designed for universal compatibility, this part fits most modern vehicles, simplifying the installation process.
HELLA 002952861 Specifications
Product Attributes
| Test Mark | ECE-R28 |
| Depth [mm] | 54 |
| Protection Type (IP Code) | 5K4K |
| Sound Level [dB(A)] | 105 |
| Temperature Range From [°c] | -40 |
| Temperature Range To [°c] | 60 |
| Voltage [V] | 12 |
| Overall Height [mm] | 122 |
| Power Consumption [w] | 66 |
| Assy./disassy. By Qualified Personnel Required! | . |
| Diameter [mm] | 97 |
| Frequency Range [hz] | 335 |
| Housing Colour | Grey |
| Supplementary Article/Info 2 | with E quality seal |
| Signal | Low Tone |
| Mounting Type | Flat Plug-in Connector |
| Homologation | ECE-R28 |
| Frequency Range From [hz] | 335 |
| Includes | (1) Universal Mounting Bracket |
| Protection | IP54 |
| Assy/Disassy by Qualified Personnel Required! | . |
| Temperature range to [°F] | 140 |
| Power Consumption [a] | 5.5 |
| Temperature range from [°F] | -40 |
| Operating Mode | Electric |
| Supplementary Article/Supplementary Info 2 | with E Quality Seal |
| Housing Color | Gray |
| ECE Regulation | R28 |
| Voltage [VDC] | 12 |
| Depth [in] | 2.13 |
| California Proposition 65 Required | No |
| Grade Type | Standard Replacement |
| Ip Rating | IPX9K |
| Diameter [in] | 3.82 |
| Wattage [W] | 66 |
| Overall Height [in] | 4.8 |
| Quantity | 1 |
| Registration Type | ECE Approved |
| Voltage | 12.00 2H |
| Color | Black / Gray |
| Decibel Rating | 105.00 |
| Terminal Type | Blade |
| Mounting Hardware Included | Yes |
| Connector Quantity | 1 |
| Mount Type | Bracket Mounting |
| Terminal Quantity | 2 |
| Mounting Bracket Included | Yes |
Additional Information
| Harmonized Tariff Code (HTS) | 8512300020 |
| Warranty Time UOM | MO |
| Warranty Time | 12 |
| Country of Origin (Primary) | IN |
| UPC | 04082300279498 |
HELLA 002952861 Cross References
| Brand | Part Number |
|---|---|
| BMW | 1 367 309, 61 33 1 367 309 |
| Bosch | 0 320 043 010, 0 320 043 020, 0 986 320 133, 0 986 320 133 090, 0 986 320 136 090 |
| Ford | 6 046 578, 6 046 579 |
| Mercedes-Benz | 001 542 85 20, 002 542 03 20, 002 542 78 20, 003 542 10 20, 003 542 16 20, 003 542 27 20, 631 542 01 20, A 001 542 85 20, A 002 542 03 20, A 002 542 78 20, A 003 542 10 20, A 003 542 16 20, A 003 542 27 20, A 631 542 01 20 |
| N/A | 5057050, 1 130 511 3, VOE11305113, 628100, 628105, 0 986 320 144, 0 986 320 132, 6 905 327, 5057050-0, 11305113-0, 74100, 22910, 6350-12-159-4983, 100 800 0043, 69481-53141, RG20153362, V10-77-0911, 56 370 046 |
| Opel | 12 28 065, 90166684 |
| Volvo | 11 305 113, 5 057 050 |
| Volvo Truck | 1 130 511 3, VOE11305113 |
