DANA part description

Specifications

Brand Spicer
Wall Thickness 11.00
Induction Hardened Spindle Y
Rolled Over N
Box Section 133 X 117
Spindle Series R
Bowl Offset 66.00
Overall Length 2078.00
Pilot Diameter 171.45
Bolt Circle Diameter 209.50
Index Angle (CCW From 12:00) 22.50
Hole Size .656+.812
Hole Pattern 15+1
VMRS 022003133
Package Type EACH
Package Qty 1
Weight 22044 LB
Country of Origin United States

Product Attributes

Pilot Diameter 171.45 in
Bolt Circle Diameter 209.50 IN
Bowl Offset 66.00 IN
Box Section 133 X 117
Hole Pattern 15+1
Hole Size .656+.812 IN
Index Angle (CCW From 12:00) 22.50
Induction Hardened Spindle Y
Rolled Over N
Spindle Series R
Wall Thickness 11.00 IN
Overall Length (mm) 2078.00 mm

Additional Information

Country of Origin (Primary) US
UPC 00023913350895
VMRS Code 022001001

Part Interchanges

Dana Holding Corporation® is an internationally known company specializing in drivetrain and e-Propulsion systems. It conceptualizes, manufactures, and supplies energy-management and power- and conveyance solutions for the present-day and future vehicles and trucks. With its over 115 years of industry experience and innovation, and despite several turbulences the automotive and trucking industry has been through, Dana has managed to take the lead in revolutionary technological inventions. Dana Holding Corporation comprises different world-renowned brands catering to various market segments. These include SPICER Drivetrain Systems, VICTOR REINZ Sealing Products, LONG Thermal Products, BREVINI Motion Systems, GRAZIANO High-Performance Transmissions, FAIRFIELD Custom Gears and Drives, and a lot more.
