*Representative image - actual part not displayed
CENTRIC 141.50514 - Semi-Loaded Brake Caliper EPB
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
CENTRIC part description
California Proposition 65 Warning
California Proposition 65 Warning
WARNING: This product can expose you to chemical which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.gov. (Read more)
Product Description
Centric Semi-Loaded Brake Caliper EPB
Application Summary
Hyundai Azera 2017
Features & Benefits
- Remanufactured to meet the most exacting standards for reliable performance. 100% pressure tested & inspected to ensure proper operation & fitment. Treated with anti-corrosion finish. Comes without brake pads. Includes hardware and brackets
Centric Calipers; Centric Parts loaded caliper; Centric; Centric Parts; CentricParts; Semi-Loaded Caliper; Centric Semi-Loaded Calipers
Product Attributes
| Pad Wear Sensor Included | No |
| Inlet Thread Diameter | 10.000 MM |
| Mounting Hardware Included | No |
| Casting Number | 3859; 3859B; |
| Pads Included | No |
| Caliper Casting Material | Cast Iron |
| Piston Quantity | 1 |
| Caliper Type | Floating |
| Friction Materials Standards Institute Pad Number | 10x.20440 |
| Bleeder Thread Diameter | 10.000 MM |
| 7609 | 38.000 MM |
| Inlet Fitting Type | Banjo |
| Caliper Color | Gray |
| Abutment Clips Included | Yes |
| Mounting Bracket Included | Yes |
| Piston Material | Steel |
| 9544 | M10-1.00 |
| 9558 | M10-1.00 |
| Axle Leading/trailing [cntrc] | Trailing |
| Bare Bracket Weight [cntrc] Lbs | 2.90 |
| Bare Caliper Body Weight [cntrc] Lbs | 4.45 |
| Bleeder Install Thread Count [cntrc] In | 4.5 |
| Bleeder Screw Included [cntrc] | Yes |
| Body Air Gap [cntrc] | 47.5mm |
| Bracket # [cntrc] | 743.50513 |
| Bracket Air Gap [cntrc] | 18.0mm |
| Bracket Required [cntrc] | Yes |
| Caliper Boot & Seal Kit# [cntrc] | 143.33039 |
| Caliper Manufacturer [cntrc] | TRW |
| Car Position [cntrc] | Left Rear |
| Finish [cntrc] | Rust Preventative |
| Hardware Kit# [cntrc] | 117.50016 |
| Mount Spread - Ctr2ctr [cntrc] | 100.0mm |
| Mount Thread Size [cntrc] Mm | M10-1.25 |
| New Or Ramanufactured [cntrc] | Remanufactured |
| Notes [cntrc] | EPB spline = 12 x 8.25 |
| Published Bore Size [cntrc] | 38 |
| Root Core# [cntrc] | 50514 |
| Rust Preventative Coating [cntrc] | Yes |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (HTS) | 8412909085 |
| NAFTA Preference Criterion Code | B |
| Original Equipment Manufacturer | CNXN |
| OEM's Part Number | 582103V500 |
| UPC | 00889590285772 |
Fits Vehicles
- Hyundai Azera (2017)
