TrakMotive GM8049 - CV Axle Shaft
- Part Number
- GM8049
- Manufacturer
- TRAKMOTIVE
- Description
-
CV Axle Shaft
details
$9799
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
TRAKMOTIVE part description
Product Description
CV Axle Shaft
Product Attributes
| ABS Ring Tooth Count | 48 |
| ABS Ring Type | Toothed |
| Abs Tone Ring Included | Yes |
| Axle Bolt Hex Size (mm) | N/A |
| Axle Bolt Length (mm) | N/A |
| Axle Bolt Thread Size | N/A |
| Axle Nut Head Type | Hex |
| Axle Nut Height (in) | .8 |
| Axle Nut Height (mm) | 20 |
| Axle Nut Hex Size (in) | 1.67 |
| Axle Nut Hex Size (mm) | 30 |
| Axle Nut Included | Yes |
| Axle Nut Length (in) | 1.33 |
| Axle Nut Length (mm) | 34 |
| Axle Nut Locking Type | Self-Lock |
| Axle Nut Thread Size | M20x1.5 |
| Boot Material | Neoprene |
| Inboard Bolt Head Size (in) | N/A |
| Inboard Bolt Head Size (mm) | N/A |
| Inboard Bolt Head Type | N/A |
| Inboard Bolt Length (in) | N/A |
| Inboard Bolt Length (mm) | N/A |
| Inboard Bolt Thread Size | N/A |
| Inboard Joint Type | Female |
| Inboard Shaft Connection Style | Female |
| New Or Remanufactured | New |
| Number of Bolt Holes | 0 |
| Number Of Inboard Joint Bolt Holes | 0 |
| Number Of Inboard Shaft Bolts | 0 |
| Number Of Inboard Splines | 34 |
| Number Of Outboard Joint Bolt Holes | 0 |
| Number Of Outboard Shaft Bolts | 0 |
| Number Of Outboard Splines | 33 |
| Outboard Bolt Head Size (in) | N/A |
| Outboard Bolt Head Size (mm) | N/A |
| Outboard Bolt Head Type | N/A |
| Outboard Bolt Length (in) | N/A |
| Outboard Bolt Length (mm) | N/A |
| Outboard Joint Bolt Thread Size | N/A |
| Outboard Joint Type | Conventional |
| Outboard Shaft Connection Style | Conventional |
| Overall Compressed Length (in) | 20.79 |
| Overall Compressed Length (mm) | 528 |
| Axle Nut Socket Size | 30 |
| Grade Type | Premium |
| Inboard Joint Boot Material | Neoprene |
| Outboard Joint Boot Material | Neoprene |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708508500 |
| UPC | 00844084030498 |
Part Interchanges
- ARC 80-2583
- EMPI 80-1238
- Car Components Technologies (CCT) 8498
- Mevotech CV5368
- Carquest 410369
- Carquest 800369
- USA Industries 708541
- USA Industries AX-8541
- Prestige Autotech 1049
- American Remanufactured 40-16250S
- Diversified Shafts Solutions 1423N
- Drive Tech America GM-6250A
- Fenwick CV3241
- CARDONE Reman 60-1216
- CARDONE Reman 60-1323
- CARDONE Reman 60-1363
- CARDONE Reman 66-1323
- CARDONE Reman MP1216
- IMC 40738140
- OEM Part Number 26059855
- OEM Part Number 26079532
- OEM Part Number 26079534
- OEM Part Number 88955449
- ODM GC-8-8654A
- TrakMotive GM-8049
- ProTech CH10510
- 410369
- NCV10585
- 70205
- 179049
TRAKMOTIVE GM8049 Cross Reference
We have 1 alternatives for the GM8049 by TRAKMOTIVE:
Fits Vehicles
- Pontiac Sunfire (1995-2005)
- Chevrolet Cavalier (1995-2005)
