(888) 312-8812 Login SignupHALDEX SC24d CHAMBER
$14499
Limited availability at this price!
In Stock
Get it by Tuesday, Dec 23
HALDEX SC24d Part Description
Manufacturer
Product Description
Service Chamber 24S Air Disc Brake
Application Summary
Service Chamber for ADB Type 24(1) unit with fasteners. 1 wheel end
Features & Benefits
- Made using high-quality materials for superior durability
- Manufactured to meet or exceed OEM standards for maximum efficiency
- Stringently tested to ensure performance and reliability
- Built to withstand even the harshest operating conditions
Haldex ADB Actuator
Keep your air brake spring brake working at its peak condition by replacing any damaged or worn ADB actuator with the Haldex ADB actuator. Manufactured by a brand with over 100 years of engineering expertise, this product is designed to offer reliable performance and long-lasting service.
HALDEX SC24d Specifications
Product Attributes
| Diaphragm Type | Single |
| Ram Stroke | 2.5 in. |
| Air Port Position | 45° |
| Freight Class | 70 |
| Service Chamber Size | 24 |
| Service Clampband Position | 225° |
| Service Housing to Push Rod Length | 0.59 in. |
| Stroke Type | Standard |
| Stud Distance | 4.75 in. |
Additional Information
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (Schedule B) | 8412310080 |
| Harmonized Tariff Code (HTS) | 8412310080 |
| Remanufactured Part | N |
| Warranty Distance | 100000 |
| Warranty Distance UOM | MI |
| Warranty Special | See Haldex Aftermarket Product warranty Policy (L20221W).pdf |
| Warranty Time | 12 |
| Warranty Time UOM | MO |
| UPC | 00767653323268 |
| VMRS Code | 013004027 |
HALDEX SC24d Part Interchanges
| Brand | Part Number |
|---|---|
| N/A | 125240101, K017463, 125240100, 1427701 |
| Haldex | 125240101 |
| Bendix | K017463, K025446 |
| Anchorloc | 125240100, 125249001 |
| MGM Brakes | 1427701, 1427702 |
| BENDIX | K017463, K025446 |
| ANCHORLOK | 125240100, 125249001 |
HALDEX SC24d Cross References
We have 4 alternatives for the SC24d by HALDEX:
HALDEX SC24d Customer Reviews
No reviews yet
Be the first to review this product!
HALDEX SC24d Manufacturer Information
Haldex® is a Sweden-based manufacturer specializing in brake and air suspension systems for heavy duty vehicles. Its product line consists of brake components for wheel ends, including disc brakes, brake adjusters, and actuators. It also offers air control products such as compressed air dryers, valves, ABS, and EBS. All these Haldex products are designed with safety and efficient operation in mind, cutting down on potential hazards and maintenance costs in the long run. Today, Haldex runs manufacturing and R&D facilities in 19 countries across four continents. It is dedicated to producing high-quality brake and suspension parts for its customers all around the world as well as developing new technologies for the future.
