(888) 312-8812 Login SignupHALDEX KN32040 VLV-DBL CHECK
Tap to view 1 more
SHIPS TODAY
$15099
Limited availability at this price!
In Stock
Get it by Thursday, Dec 18
HALDEX KN32040 Part Description
Manufacturer
Product Description
Quick Release Valve with Two-Way Check
Features & Benefits
- Used primarily in spring brake control circuits to prevent compounding on trucks and tractors
- Designed to replace two valves
- With oil-resistant diaphragm and disk to offer long-lasting service
- Stringently evaluated to ensure reliability, performance, and high efficiency
- All Haldex valves are designed for trouble-free air brake system repair and maintenance
Haldex Air Brake Quick Release Valve
Maintain high air brake performance with a premium-quality Haldex air brake quick release valve. Manufactured by a brand with a solid reputation in manufacturing top-quality air brake system components, this valve effectively exhausts brake chamber air pressure and speeds up brake release. It does this by reducing the distance the air would have to travel back to the brake valve exhaust port.
HALDEX KN32040 Specifications
Product Attributes
| Control Port Diameter | 1/4 in. |
| Delivery Port Diameter | 2 @ 1/4 in. |
| Freight Class | 70 |
| Mounting Centers | 1.5 in. |
Additional Information
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (Schedule B) | 8481200070 |
| Harmonized Tariff Code (HTS) | 8481200070 |
| Remanufactured Part | N |
| Warranty Distance | 100000 |
| Warranty Distance UOM | MI |
| Warranty Special | 36 MO, 350,000 MI=Haldex Air Brake Valves(1), Automatic Drain Valves (410-10XXX Series)(1). 12 MO, 100,000 MI= Automatic Drain Valves (N20878/ N20879 Series), Height Control Valve, Scale-O-Matic and AC Boxes. See L20221W.pdf for warranty details |
| Warranty Time | 12 |
| Warranty Time UOM | MO |
| UPC | 00767653011141 |
| VMRS Code | 013010008 |
HALDEX KN32040 Part Interchanges
| Brand | Part Number |
|---|---|
| N/A | E-BN289182X, N20952AC, 289182, 0833-MM5, 106899, 9340990240, EM-36260, SFMB34620024, 289714, P-66999, 2022480, 569-35-61120, 1676744C1, 90015034, 801566, U55 KN32040, V1093106, WA289182, 289182N, RB-289182, AV289714, 401279 |
| Euclid | E-BN289182X, E-BN289714X, E-KN32040X |
| Haldex | N20952AC |
| Midland | 289182, 289182A, 289182X, 289714X, KN32040, KN32040X, N20952AA, N20952AB, N20952AC |
| Prior | 289182 |
| Spartan | 0833-MM5 |
| Bendix | 106899, 108892, 289182, 289714, 801369 |
| Meritor | 9340990240, RKN32040, RN20952AB |
| PAI | EM-36260, EM-57180 |
| AM General | SFMB34620024 |
| Bepco | 289714 |
| Dana Commercial Vehicle Service Parts | P-66999 |
| GMC | 2022480, 2022481, 2022482 |
| Komatsu | 569-35-61120 |
| Navistar | 1676744C1, ZZKN32040 |
| Ottawa | 90015034 |
| Paccar Parts | 801566 |
| Ryder | U55 KN32040 |
| Volvo GM Heavy Truck | V1093106 |
| World American | WA289182, WA289714 |
| NAPA | 289182N, 289714N, 66999 |
| RANGER BRAKE | RB-289182, RB-289714 |
| OTR | AV289714 |
| Tramec Sloan | 401279 |
| EUCLID | E-BN289182X, E-BN289714X, E-KN32040X |
| MIDLAND | 289182, 289182A, 289182X, 289714X, KN32040, KN32040X, N20952AA, N20952AB, N20952AC |
| PRIOR | 289182 |
| SPARTAN | 0833-MM5 |
| BENDIX | 106899, 108892, 289182, 289714, 801369 |
| MERITOR | 9340990240, RKN32040, RN20952AB |
| DANA | P-66999 |
| NAVISTAR | 1676744C1, ZZKN32040 |
| RYDER FLEET PROD. | U55 KN32040 |
| WORLD AMERICAN | WA289182, WA289714 |
HALDEX KN32040 Cross References
We have 1 alternatives for the KN32040 by HALDEX:
HALDEX KN32040 Manufacturer Information
Haldex® is a Sweden-based manufacturer specializing in brake and air suspension systems for heavy duty vehicles. Its product line consists of brake components for wheel ends, including disc brakes, brake adjusters, and actuators. It also offers air control products such as compressed air dryers, valves, ABS, and EBS. All these Haldex products are designed with safety and efficient operation in mind, cutting down on potential hazards and maintenance costs in the long run. Today, Haldex runs manufacturing and R&D facilities in 19 countries across four continents. It is dedicated to producing high-quality brake and suspension parts for its customers all around the world as well as developing new technologies for the future.
