*Representative image - actual part not displayed
Dana 220TB106-3 - Steer Axle Beam
$7,34749
206 day lead time
limited availability at this price!
. Learn more
DANA part description
| Brand: | Spicer |
| Type: | I-Beam |
| Spring Mount Center to Center (MM): | 812.8 |
| Spring Mount Center to Center (IN): | 32 |
| Center Drill Dia And Depth (MM): | 20.625 x 19.812 |
| Center Drill Dia And Depth (IN): | .812 x .780 |
| Otr Drill Patrn # And Dia (MM): | 4 x 26.970 |
| Otr Drill Patrn # And Dia (IN): | 4 x 1.062 |
| Center Hole to Center Out Patrn (MM): | 64.29 |
| Center Hole to Center Out Patrn (IN): | 2.531 |
| Drill Pattern Width (MM): | 128.57 |
| Drill Pattern Width (IN): | 5.062 |
| Drill Pattern Length (MM): | 127 |
| Drill Pattern Length (IN): | 5 |
| VMRS: | 11001033 |
| Package Type: | Each |
| Package Quantity: | 1 |
| Weight: | 319.01 lbs. |
| Country of Origin: | Mexico |
| UPC Code: | 023913209230 |
Features & Benefits
- Genuine Spicer Product
- Meets or exceeds OE standards
- Engineered to be stronger than ever
- Delivers optimal performance in your vehicle
Product Attributes
| Type | I-Beam |
| Ctr Drill Dia And Depth (IN) | .812 x .780 IN |
| Ctr Drill Dia And Depth (MM) | 20.625 x 19.812 MM |
| Ctr Hole To Ctr Out Patrn (IN) | 2.531 IN |
| Ctr Hole To Ctr Out Patrn (MM) | 64.29 MM |
| Drill Pattern Length (IN) | 5.000 IN |
| Drill Pattern Length (MM) | 127.00 MM |
| Drill Pattern Width (IN) | 5.062 IN |
| Drill Pattern Width (MM) | 128.57 MM |
| Otr Drill Patrn # And Dia (IN) | 4 x 1.062 IN |
| Otr Drill Patrn # And Dia (MM) | 4 x 26.970 MM |
| Spring Mount Ctr To Ctr (IN) | 32.00 IN |
| Spring Mount Ctr To Ctr (MM) | 812.8 MM |
Additional Information
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (Schedule B) | 8708990000 |
| Harmonized Tariff Code (HTS) | 8708990000 |
| UPC | 00023913209230 |
| VMRS Code | 011001033 |
Part Interchanges
Dana Holding Corporation® is an internationally known company specializing in drivetrain and e-Propulsion systems. It conceptualizes, manufactures, and supplies energy-management and power- and conveyance solutions for the present-day and future vehicles and trucks. With its over 115 years of industry experience and innovation, and despite several turbulences the automotive and trucking industry has been through, Dana has managed to take the lead in revolutionary technological inventions. Dana Holding Corporation comprises different world-renowned brands catering to various market segments. These include SPICER Drivetrain Systems, VICTOR REINZ Sealing Products, LONG Thermal Products, BREVINI Motion Systems, GRAZIANO High-Performance Transmissions, FAIRFIELD Custom Gears and Drives, and a lot more.
