GATES part description
Product Description
TH7S Hydraulic Thermoplastic Hose - SAE 100R7
Features & Benefits
- For use with MegaCrimp Couplings [G25 Series]
- TH7S hose meets or exceeds performance requirements of SAE 100R7 with a significantly tighter bend radius
- Temperature Range: Petroleum and Synthetic Oils: -65 Deg. F to +200 Deg. F (-54 Deg. C to +93 Deg. C) constant
Product Attributes
| Coupling Recommendation | MegaCrimp |
| SAE Standard | 100R7 |
| EN Standard | N/A |
| ISO Standard | N/A |
| Product Type | TH7S Hydraulic Hose - SAE 100R7 |
| Industrial Description | 5TH7SX50FT |
| Type | Thermoplastic Hydraulic Hose |
| Hose Pressure Description | Medium Pressure |
| Maximum Working Pressure | 2500 PS |
| Burst Pressure | 10000 PS |
| Temperature Rating | -65 Deg. F to +200 Deg. F (-54 Deg. C to +93 Deg. C) |
| Length | 50 FT |
| Dash Size | 5 |
| Inside Diameter | .3125 IN |
| Outside Diameter | .56 IN |
| Bend Radius | 1.75 IN |
| Tube Description | Polyester |
| Hose Material | Polyester |
| Reinforcement Material | Synthetic Fiber |
| Cover Material | Urethane - Perforated for Use in General Hydraulic & Pneumatic Service |
| Cover Type | Resistant to Hydraulic Fluid, High Temperature, Aging & Weathering |
| Cover Color | Black |
Additional Information
| Harmonized Tariff Code (Schedule B) | 3917310000 |
| Country of Origin (Primary) | US |
| UPC | 00072053295047 |
| VMRS Code | 059032029 |
| UNSPSC | 40142020 |
Part Interchanges
