Centric 123.62025 - C-Tek Standard Brake Drum
$13549
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
Product Attributes
| Misc Holes [cntrc] | 3 |
| Weight [cntrc] Kgs | 9.091 |
| Weight [cntrc] Lbs | 20.000 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 127.000 |
| Bolt Circle Diameter [cntrc] In | 5.000 |
| Hub Hole / Register [cntrc] Mm | 77.978 |
| Hub Hole / Register [cntrc] In | 3.070 |
| Height [cntrc] Mm | 102.108 |
| Height [cntrc] In | 4.020 |
| Friction Surface Width [cntrc] Mm | 71.374 |
| Friction Surface Width [cntrc] In | 2.810 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 280.900 MM |
| Maximum Brake Diameter (Discard) | 11.060 IN |
| Bolt Hole Quantity | 5 |
| Outside Diameter | 329.946 MM |
| Outside Diameter | 12.990 IN |
| Outer Cooling Fins | Yes |
| Mounting Hole Diameter | 13.462 MM |
| Mounting Hole Diameter | 0.530 IN |
| Nominal Drum Diameter | 279.400 MM |
| Nominal Drum Diameter | 11.000 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890915058 |
Part Interchanges
CENTRIC 123.62025 Cross Reference
We have 2 alternatives for the 123.62025 by CENTRIC:
Fits Vehicles
- Checker Taxicab (1970-1971)
- Pontiac Tempest (1967-1969)
- Pontiac Executive (1967-1970)
- Pontiac Star Chief (1959-1966)
- Pontiac Grand Prix (1964-1968)
- Pontiac Catalina (1965-1970)
- Pontiac Bonneville (1965-1970)
- Checker Marathon (1970-1971)
