Name: Dana 3-1-303-7 Drive Shaft Companion Flange
SKU: 313037
Price: 280.99 USD
Availability: InStock

DANA part description

Brand:	Spicer
Flange Type:	Circular
Series:	1350
Flange Width Diameter (A) IN.:	4.56
Bolt Circle Diameter (B) IN.:	3.75
Number of Holes:	4
Bore Diameter (D) IN.:	1.75
Key Width (K) IN.:	0.377
Pilot Diameter (C) IN.:	2.750 - FEMALE
Set Screw Hole Diameter IN.:	0.375
Hub Diameter (E) IN.:	2.875
Circ Flnge Face to End of Hub:	3.44
Bolt Hole Diameter (IN.):	.440 - DRILLED
Material:	Steel
VMRS:	24002040
Actual Hole Diameter (Max):	1.75
Actual Hole Diameter (Min):	1.749
Actual Keyway Width (Max):	0.378
Actual Keyway Width (Min):	0.376
Package Type:	Each
Package Quantity:	1
Weight:	4.23 lbs.
Country of Origin:	United States
UPC Code:	023913235338

Features & Benefits

Genuine OE quality. Tested and proven.
Built to meet OE standards set by Dana.
Tested and validated to rigorous OE specifications.
Latest production upgrades ensure genuine Spicer parts are as good or better than the OE parts they replace.

Product Attributes

Series	1350
Material	Steel
NUMBER OF HOLES	4
Pilot Diameter (C) In.	2.750 - FEMALE IN
Bolt Circle Diameter (B) In.	3.750 IN
FLANGE TYPE	Circular
Actual Hole Diameter (Max)	1.750 IN
Actual Hole Diameter (Min)	1.749 IN
Actual Keyway Width (Max)	0.378 IN
Actual Keyway Width (Min)	0.376 IN
Bore Diameter (D) In.	1.750 IN
Circ Flnge Face To End Of Hub	3.440 IN
Flange Width Diameter (A) In.	4.56 IN
Hub Diameter (E) In.	2.875 IN
Key Width (K) In.	0.377 IN
Set Screw Hole Diameter In.	0.375 IN
Bolt Hole Diameter (In.)	.440 - DRILLED IN

Additional Information

Country of Origin (Primary)	US
Harmonized Tariff Code (Schedule B)	8708990000
Harmonized Tariff Code (HTS)	8708990000
UPC	00023913235338
VMRS Code	024002040
