TrakMotive NI-8115 - CV Axle Shaft
- Part Number
- NI-8115
- Manufacturer
- TRAKMOTIVE
- Description
-
CV Axle Shaft
details
$7749
MSRP: $111.99
Save: $34.50
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
TRAKMOTIVE part description
Product Description
CV Axle Shaft
Product Attributes
| ABS Ring Tooth Count | 44 |
| ABS Ring Type | Toothed |
| Abs Tone Ring Included | Yes |
| Axle Bolt Hex Size (mm) | N/A |
| Axle Bolt Length (mm) | N/A |
| Axle Bolt Thread Size | N/A |
| Axle Nut Head Type | Hex |
| Axle Nut Height (in) | .67 |
| Axle Nut Height (mm) | 18 |
| Axle Nut Hex Size (in) | 1.4 |
| Axle Nut Hex Size (mm) | 36 |
| Axle Nut Included | Yes |
| Axle Nut Length (in) | 1.6 |
| Axle Nut Length (mm) | 41 |
| Axle Nut Locking Type | Cotter Pin |
| Axle Nut Thread Size | M24x1.5 |
| Boot Material | Neoprene |
| Inboard Bolt Head Size (in) | N/A |
| Inboard Bolt Head Size (mm) | N/A |
| Inboard Bolt Head Type | N/A |
| Inboard Bolt Length (in) | N/A |
| Inboard Bolt Length (mm) | N/A |
| Inboard Bolt Thread Size | N/A |
| Inboard Joint Type | Male |
| Inboard Shaft Connection Style | Male |
| New Or Remanufactured | New |
| Number of Bolt Holes | 0 |
| Number Of Inboard Joint Bolt Holes | 0 |
| Number Of Inboard Shaft Bolts | 0 |
| Number Of Inboard Splines | 25 |
| Number Of Outboard Joint Bolt Holes | 0 |
| Number Of Outboard Shaft Bolts | 0 |
| Number Of Outboard Splines | 27 |
| Outboard Bolt Head Size (in) | N/A |
| Outboard Bolt Head Size (mm) | N/A |
| Outboard Bolt Head Type | N/A |
| Outboard Bolt Length (in) | N/A |
| Outboard Bolt Length (mm) | N/A |
| Outboard Joint Bolt Thread Size | N/A |
| Outboard Joint Type | Conventional |
| Outboard Shaft Connection Style | Conventional |
| Overall Compressed Length (in) | 24.33 |
| Overall Compressed Length (mm) | 618 |
| Axle Nut Socket Size | 36 |
| Grade Type | Premium |
| Inboard Joint Boot Material | Neoprene |
| Outboard Joint Boot Material | Neoprene |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708508500 |
| UPC | 00844084071156 |
Part Interchanges
- ARC 80-5597
- EMPI 80-4315
- Car Components Technologies (CCT) 5055
- Mevotech CV3402
- USA Industries 7095039
- USA Industries AX-95039
- American Remanufactured 40-19503S
- Diversified Shafts Solutions 7983N
- Drive Tech America NI-9503A
- Fenwick CV2370
- CARDONE Reman 60-6222
- CARDONE Reman 66-6222
- IMC 40738105
- Carquest Premium AC NCV39521
- OEM Part Number 391017J116
- ODM NI-8-8590A
- TrakMotive NI-8115
- ProTech NI20503
- Value Advantage C9101-7J1AK-NW
- NCV39521
- 95101
- 259115
- C91017J1AK
Fits Vehicles
- INFINITI G20 (1999-2002)
