DANA part description

Series: 1410
Material: Steel
Tube Size: 4.000 x 0.083 in.
CL Yoke to CL Yoke - COLL.: 78.33 in.

Product Description

Features & Benefits

  • Slip Yoke One End
  • Flange Yoke One End
  • 78.33 Inch Overall Length
  • Dana manufactured Spicer Driveshafts are designed, engineered, tested, and manufactured to meet or exceed OE requirements.
  • Dana manufactured Spicer driveshafts are designed to be drop-in replacements, eliminating assembly time.

Product Attributes

Series 1410
Tube Size (in) 4.000 X 0.083 IN
Tube Size (mm) 101.600 X 2.110 mm
Cl Yoke To Cl Yoke(IN) - COLL. 78.330 IN
Cl Yoke To Cl Yoke(MM) - COLL. 1608.0000 MM
Shaft Material Steel
Max Slip (MM) 4.00 x .083
CL (Yoke To Bearing) (MM) 63.3071

Additional Information

Country of Origin (Primary) US
Harmonized Tariff Code (Schedule B) 8708998180
Harmonized Tariff Code (HTS) 8708998180
UPC 00023913640248
VMRS Code 024000000

Part Interchanges

Fits Vehicles

  • Ford F-350 Super Duty (2011-2016)
  • Ford F-250 Super Duty (2011-2016)
