CURT MANUFACTURING part description

Product Description

TruTrack 4P Weight Distribution Hitch with 4x Sway Control; 8-10K

Features & Benefits

  • Integrated sway control actively resists sway and levels the vehicle and trailer
  • Four points of sway control work together to keep trailer aligned
  • Welded head with cast pieces and trunnion-style forged steel spring bars
  • Uses spring & cam system with hardened components, instead of friction alone
  • Adjustable brackets provide fixed support unlike spring bar chain models
  • Brackets use friction to resist lateral movement, replacing a sway control
  • 2" shank can be flipped to provide necessary drop or rise
  • Hex castle nut allows for easy adjustment for different trailers
  • Fits virtually all A-frame trailers, featuring two neutral spring bar settings
  • Carbide black powder coat, black-oxide-plated cams and stainless steel balls
  • Includes a pre-torqued 2-5/16" trailer ball
  • Limited lifetime warranty (one-year finish, one-year parts)
  • Sway Control Resists Sway And Levels The Vehicle And Trailer
  • Tilt Adjustment Feature Simplifies Setup And Installation
  • Fixed Support Brackets Hold The Spring Bars In Place
  • Use Friction To Resist Movement Replacing A Sway Control
  • Cast Head And Hardened Cams Provide Solid Attachment
  • Cam Springs Build Up Pressure For Integrated Sway Control
  • Equipped w/Trunnion-Style Forged Steel Spring Bars
  • 12 In. Adjustable Shank Fits 2 In. X 2 In. Receiver Tube Openings
  • Two Neutral Bar Settings For Narrow And Wide A-Frame Trailers
  • Protected By A Highly Durable Carbide Powder Coat Finish
  • Incl. A Pre-Torqued 2 5/16 In. Trailer Ball

Integrated sway control actively resists sway and levels the vehicle and trailer

Product Attributes

Color Black
Finish Carbide Black Powder Coat
Gross Trailer Weight 10000 lbs.
Tongue Weight 1000 lbs.
WARNING CA Proposition 65 No
WC Tongue Weight 1000
Warranty Limited Lifetime Warranty (One-Year Finish, One-Year Parts)
Box Height In Inches - Xa 0
Box Length In Inches - Xa 0
Box Width In Inches - Xa 0
Class Id 0
Color Black
Container Cases Qty - XA 300
Container Load Type - XA PALLETS
Container Pallet Qty - XA 20
Container Type - XA 40GP
Container Unit Qty - XA 300
Container Volume Cubic Feet - XA 0.00000
Container Volume Cubic Meter - XA 0.00000
Container Weight KG - XA 0
Container Weight Lbs - XA 36580
Finish - Xa CARBIDE BLACK POWDER COAT
Gross Trailer Weight (gtw) 10,000 LB
Item Class - Xa OBS
Item Height - Xa 11.500
Item Length - Xa 37.000
Item Width - Xa 13.000
Master Case Height Inches - XA 11.600
Master Case Inner Pack Qty - XA 0
Master Case ITF14 0
Master Case ITF14 - XA 0
Master Case Length Inches - XA 13.800
Master Case Qty - XA 1
Master Case Volume Cubic Feet - XA 0.00000
Master Case Weight Lbs - XA 119.000
Master Case Width Inches - XA 37.400
Material - Xa Carbon Steel
Mount Type Description - Xa Blank
Pallet Case Per - XA 15
Pallet Case Per Layer - XA 3
Pallet Cases Per - XA 15
Pallet Cases Per Layer - XA 3
Pallet Layer of Cases - XA 5
Pallet Qty - XA 0.000
Pallet Total Height Inches - XA 63.400
Pallet Total Weight Per - XA 1829.000
Parcel Allowed - Xa Yes
Product Weight - Xa 121.300
Prop 65 Label Text - XA Blanks
Prop 65 Material - XA Unknown
Prop 65 Reason - XA Unknown
Prop 65 Warning Label Type - XA Unknown
Prop 65 Warning Y/N - XA NO
Rate Class - Xa 60.0
Retail Height - Xa 11.500
Retail Length - Xa 37.000
Retail Width - Xa 13.000
Sales Family Code - Xa WDIST
Sales Family Description - Xa WEIGHT DISTRIBUTION
Sales Group Description - Xa TRUTRACK WD SYSTEM
Shipping Weight - Xa 121.300
Side Application Type Description - Xa Blank
Tariff 301 - Xa Yes
Title TruTrack 4P Weight Distribution Hitch with 4x Sway Control, 8-10K
Tongue Weight (tw) 1,000 LB
Truckload Cases Qty - XA 0
Truckload Pallets Qty - XA 0
Truckload Units Qty - XA 0
Truckload Volume Cubic Feet - XA 0.00000
Truckload Weight - XA 0

Additional Information

Country of Origin (Primary) CN
Harmonized Tariff Code (Schedule B) 8708998180
Harmonized Tariff Code (HTS) 8708998180
NAFTA Preference Criterion Code B
Warranty Special Limited Lifetime Warranty (One-Year Finish, One-Year Parts)
Warranty Special UOM TX
UPC 00612314175000
