CURT MANUFACTURING part description

Product Description

TruTrack 4P Weight Distribution Hitch with 4x Sway Control; 10-15K

Features & Benefits

  • Adjustable brackets provide fixed support unlike spring bar chain models
  • Brackets use friction to resist lateral movement, replacing a sway control
  • 2" shank can be flipped to provide necessary drop or rise
  • Fits virtually all A-frame trailers, featuring two neutral spring bar settings
  • Carbide black powder coat, black-oxide-plated cams and stainless steel balls
  • Includes a pre-torqued 2-5/16" trailer ball
  • Limited lifetime warranty (one-year finish, one-year parts)
  • Integrated sway control actively resists sway and levels the vehicle and trailer
  • Four points of sway control work together to keep trailer aligned
  • Welded head with cast pieces and trunnion-style forged steel spring bars
  • Uses spring & cam system with hardened components, instead of friction alone
  • Sway Control Resists Sway And Levels The Vehicle And Trailer
  • Cast Head/Hardened Cams Provide Solid Attach./Resist Wear
  • Cam Springs Build Up Pressure For Integrated Sway Control
  • Fixed Support Brackets Hold The Spring Bars In Place
  • Uses Friction To Resist Lateral Movement Replacing A Sway Control
  • Equipped w/Trunnion-Style Forged Steel Spring Bars
  • 12 In. Adjustable Shank Fits 2 In. X 2 In. Receiver Tube Openings
  • Hex Castle Nut Allows For Easy Adjustment For Different Trailers
  • Brackets Use Friction To Resist Movement Replacing A Sway Control
  • Protected By A Highly Durable Carbide Powder Coat Finish
  • Incl. A Pre-Torqued 2 5/16 In. Trailer Ball
  • Backed By A 10-Year Limited Warranty

Integrated sway control actively resists sway and levels the vehicle and trailer

Product Attributes

Finish Carbide Black Powder Coat
Gross Trailer Weight 10000 lbs.- 15000 lbs.
Tongue Weight 1500 lbs.
WARNING CA Proposition 65 No
WC Tongue Weight 1000 - 1500
Pallet Qty - XA 0.000
Pallet Total Height Inches - XA 63.400
Pallet Total Weight Per - XA 1859.000
Parcel Allowed - Xa Yes
Product Weight - Xa 123.600
Prop 65 Label Text - XA Blanks
Prop 65 Material - XA Unknown
Prop 65 Reason - XA Unknown
Prop 65 Warning Label Type - XA Unknown
Prop 65 Warning Y/N - XA NO
Rate Class - Xa 300.0
Retail Height - Xa 11.500
Retail Length - Xa 38.000
Retail Width - Xa 13.800
Rise 5.75 IN
Sales Family Code - Xa WDIST
Sales Family Description - Xa WEIGHT DISTRIBUTION
Sales Group Description - Xa TRUTRACK WD SYSTEM
Shipping Weight - Xa 123.600
Side Application Type Description - Xa Blank
Tariff 301 - Xa Yes
Title TruTrack 4P Weight Distribution Hitch with 4x Sway Control, 10-15K
Tongue Weight (tw) 1,000 LB - 1,500 LB
Truckload Cases Qty - XA 0
Truckload Pallets Qty - XA 0
Truckload Units Qty - XA 0
Truckload Volume Cubic Feet - XA 0.00000
Truckload Weight - XA 0
Warranty Limited Lifetime Warranty (One-Year Finish, One-Year Parts)
Box Height In Inches - Xa 0
Box Length In Inches - Xa 0
Box Width In Inches - Xa 0
Class Id 0
Container Cases Qty - XA 300
Container Load Type - XA PALLETS
Container Pallet Qty - XA 20
Container Type - XA 40GP
Container Unit Qty - XA 300
Container Volume Cubic Feet - XA 0.00000
Container Volume Cubic Meter - XA 0.00000
Container Weight KG - XA 0
Container Weight Lbs - XA 37180
Drop 0 IN
Finish - Xa CARBIDE BLACK POWDER COAT
Gross Trailer Weight (gtw) 10,000 LB - 15,000 LB
Item Class - Xa OBS
Item Height - Xa 0.000
Item Length - Xa 0.000
Item Width - Xa 0.000
Master Case Height Inches - XA 11.600
Master Case Inner Pack Qty - XA 0
Master Case ITF14 0
Master Case ITF14 - XA 0
Master Case Length Inches - XA 13.800
Master Case Qty - XA 1
Master Case Volume Cubic Feet - XA 0.00000
Master Case Weight Lbs - XA 121.000
Master Case Width Inches - XA 37.400
Material - Xa Carbon Steel
Mount Type Description - Xa Blank
Pallet Case Per - XA 15
Pallet Case Per Layer - XA 3
Pallet Cases Per - XA 15
Pallet Cases Per Layer - XA 3
Pallet Layer of Cases - XA 5

Additional Information

Country of Origin (Primary) CN
Harmonized Tariff Code (Schedule B) 8708998180
Harmonized Tariff Code (HTS) 8708998180
NAFTA Preference Criterion Code B
Warranty Special Limited Lifetime Warranty (One-Year Finish, One-Year Parts)
Warranty Special UOM TX
UPC 00612314175017
