Bilstein 25-291315 - SUSPENSION SHOCK ABSORBER
$1,48199
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
BILSTEIN part description
SUSPENSION SHOCK ABSORBER
Product Description
B8 8100 (Bypass) - Suspension Shock Absorber
Application Summary
Jeep Wrangler 2017-2007, Wrangler JK 2018
Features & Benefits
- Dual tube external bypass offers position sensitive damping with independent adjustment for rebound and compression
- Incremental flow adjuster offers finite and incremental changes in damping force for precise adjustments
- 60mm large bore hard anodized aluminum piston offers a greater range of damping control and delivers exceptional long-term durability
Product Attributes
| Internal Design | Monotube |
| Adjustable Damping | Double Adjustable Compression and Rebound with Click Adjuster Knobs |
| Body Diameter (id) | 60mm |
| Lower Mount Type | Eye 12.1mm |
| Parttype | Shocks / Struts |
| Prop 65 (Y/N) | Y |
| Series | B8 8100 (Bypass) |
| Extended Length (in) | 27.83 |
| Segment | Light Truck |
| Finish | EVO Grey |
| Collapsed Length (mm) | 436.0 |
| Title | Bilstein Shock Absorbers |
| Boot Included | No |
| Body Design | Bypass Body (Non-Coilover) |
| RESERVOIR | Yes |
| Spring Seat Included | No |
| Upper Mount Type | Bar Pin |
| Collapsed Length (in) | 17.17 |
| Extended Length (mm) | 707.0 |
Additional Information
| MSDS Sheet Number | USA SDS_Shock_Air Spring_V2_EN.pdf |
| Remanufactured Part | N |
| Refurbished Part | N |
| Warranty Time | 24 |
| Warranty Time UOM | MO |
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00651860857695 |
Part Interchanges
About BILSTEIN Of America Founded in 1873, BILSTEIN is a world leading manufacturer of monotube gas pressure shock absorbers. With their main headquarters located in Germany, BILSTEIN is an original equipment supplier to BMW, Jaguar, Mercedes-Benz, Porsche, GM, Chrysler, Ford, Toyota and many others. Today, BILSTEIN Aftermarket and Motorsports has grown to nearly 630 employees located in three locations around the United States and distributes more than 3,500 part numbers into the U.S. aftermarket. BILSTEIN operates within ThyssenKrupp Component Technologies Group.Fits Vehicles
- Jeep Wrangler JK (2018)
- Jeep Wrangler (2007-2017)
